Ferrari Portofino M — [VEHICLE TRIM] - E.57.02 - AC SYSTEM - AIR CONDITIONER SYSTEM (diagram 0170)

Exploded view of the [vehicle trim] - e.57.02 - ac system - air conditioner system on the Ferrari Portofino M, with 75 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Portofino M [VEHICLE TRIM] - E.57.02 - AC SYSTEM - AIR CONDITIONER SYSTEM exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14569480Ferrari Clip 10x3.8 Black - 14569480$0.54Available, ships in 3-6 days
262112Ferrari Collar - 262112SupersededOrder 262111 instead
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
13442484Ferrari Gasket - 13442484SupersededOrder 11342484 instead
766930Ferrari Hvac Inlet Hose - 766930SupersededOrder 789065 instead
14066017Ferrari Nut - 14066017$5.65Special order, ships in 7-14 days
216568Ferrari Screw 6x30 - 216568SupersededOrder 231621 instead
10860270Ferrari Screw Collar - 10860270$1.94Available, ships in 3-6 days
10860370Ferrari Screw Collar - 10860370$3.26Special order, ships in 7-14 days
13127770Ferrari Screw Collar - 13127770$2.82Special order, ships in 7-14 days
268210Ferrari Screw Collar - 268210$6.32Special order, ships in 7-14 days
766929Ferrari Tubo Rigido Da Pompa A Hvac - 766929SupersededOrder 789065 instead
12643711Ferrari Washer - 12643711SupersededOrder 12643724 instead
12643721Ferrari Washer - 12643721SupersededOrder 12643724 instead
14499301Ferrari Washer - 14499301SupersededOrder 12643724 instead
14303324Ferrari/Maserati Screw - 14303324$0.29In stock
188408300Ferrari Condensate Drain Pipe - 88408300$83.68Special order, ships in 7-14 days
289274100Ferrari Sensore Temperatura - 89274100$157.34Special order, ships in 7-14 days
3813982Ferrari Tubo Rigido Da Motore A Pomp - 813982$295.43Special order, ships in 7-14 days
4262111Ferrari Screw Collar - 262111$3.03Special order, ships in 7-14 days
5813983Ferrari Manicotto Ingresso Pompa - 813983$216.66Special order, ships in 7-14 days
6217854Ferrari CLAMP - 217854$0.52Available, ships in 3-6 days
7790253Ferrari Clip - 790253$4.35Special order, ships in 7-14 days
8813123Ferrari Clip - 813123$6.98Special order, ships in 7-14 days
9248061Ferrari Clip - 248061$4.12Available, ships in 3-6 days
9304443Ferrari Clip - 304443$1.36Special order, ships in 7-14 days
9794586Ferrari Clip - 794586$1.36Special order, ships in 7-14 days
10291349Ferrari Idle Water Recirculation Pump - 291349$5,509.80Special order, ships in 7-14 days
11766926Ferrari Recirculation Pump Mounting Bracket - 766926$29.52Special order, ships in 7-14 days
12291645Ferrari Clip - 291645$8.07Special order, ships in 7-14 days
13766928Ferrari Manicotto Uscita Pompa Ricir - 766928$51.67Special order, ships in 7-14 days
14789065Ferrari Hvac Inlet Hose - 789065$443.17Special order, ships in 7-14 days
1588418000Ferrari Ac Control Panel - 88418000$1,849.95Special order, ships in 7-14 days
1612643724Ferrari/Maserati Washer - 12643724$0.20In stock
17149707Ferrari Spacer - 149707$2.13Available, ships in 3-6 days
18103549Ferrari Grommet - 103549$2.80In stock
19231621Ferrari Allen Screw M6 x 30 TCEI - 231621$0.73Available, ships in 3-6 days
2014303224Ferrari Screw 4x16 - 14303224$1.15Special order, ships in 7-14 days
21340010Ferrari Clip - 340010$3.03Special order, ships in 7-14 days
22342226Ferrari Return Pipe From Ac Unit To - 342226$162.48Special order, ships in 7-14 days
23808101Ferrari IHX Pipe - 808101$1,551.20Special order, ships in 7-14 days
23785613Ferrari Tubazione Ihx - 785613SupersededOrder 808101 instead
2414066021Ferrari Nut - 14066021$5.86Special order, ships in 7-14 days
2513839624Ferrari Screw - 13839624$7.63Special order, ships in 7-14 days
26239094Ferrari Clip - 239094$2.59Special order, ships in 7-14 days
26267177Ferrari Clip D.20-21.5 - 267177$2.01Special order, ships in 7-14 days
27807281Ferrari Bracket - A/C Pipe from Condensor to IHX - 807281$36.92Special order, ships in 7-14 days
2814040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
2910441290Ferrari P Clip Bracket With Sheath 28mm D.10 - 10441290$1.02Available, ships in 3-6 days
3014040614Ferrari Flanged Nut 6mm - 14040614$0.27Available, ships in 3-6 days
31796455Ferrari Tubo Da Condensatore A Ihx - 796455$590.91Special order, ships in 7-14 days
32225408Ferrari Cylindrical Bushing - 225408$12.99Special order, ships in 7-14 days
3314039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
3315896214Ferrari Nut M6 x 5 - 15896214SupersededOrder 14039614 instead
34796453Ferrari Pipe from Compressor Disconnect - 796453$216.66Special order, ships in 7-14 days
35294693Ferrari Clip - 294693$8.05Special order, ships in 7-14 days
3613837017Ferrari Screw 6X30 - 13837017$7.19Special order, ships in 7-14 days
37769202Ferrari RH HVAC Unit to Cross Member Bracket - 769202$61.52Special order, ships in 7-14 days
3789389300Ferrari RH HVAC Unit to Cross Member Bracket - 89389300$56.60Special order, ships in 7-14 days
3889389200Ferrari LH HVAC Unit to Cross Member Bracket - 89389200$56.60Special order, ships in 7-14 days
3981045300Ferrari Screw 6x16 - 81045300$1.36Special order, ships in 7-14 days
40262109Ferrari Screw Collar - 262109$2.01Available, ships in 3-6 days
4111084284Ferrari Gasket - 11084284$10.46Special order, ships in 7-14 days
4211342784Ferrari Washer 3/4" - 11342784$19.42Available, ships in 3-6 days
4311342484Ferrari Gasket - 11342484$10.46Special order, ships in 7-14 days
4411342584Ferrari Washer 1/2" - 11342584$19.42Available, ships in 3-6 days
4514452884Ferrari Gasket - 14452884$34.94Special order, ships in 7-14 days
4611084084Ferrari Gasket - 11084084$10.46Special order, ships in 7-14 days
4714450483Ferrari Gasket - 14450483$10.46Special order, ships in 7-14 days
4810318884Ferrari Gasket - 10318884$10.46Special order, ships in 7-14 days
4910319184Ferrari Gasket - 10319184$10.48Available, ships in 3-6 days
5014450683Ferrari Gasket - 14450683$10.48Special order, ships in 7-14 days
5155029869Ferrari LP Plug - 55029869$21.60Special order, ships in 7-14 days
5255029871Ferrari High Pressure Cap - 55029871$23.57Special order, ships in 7-14 days
5355029938Ferrari Valve Mechanism - 55029938$34.40Special order, ships in 7-14 days
