Ferrari Portofino M — [ELECTRICAL SYSTEM] - F.9 - LIGHTING SYSTEMS (diagram 0184)
Exploded view of the [electrical system] - f.9 - lighting systems on the Ferrari Portofino M, with 39 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [ELECTRICAL SYSTEM] - F.9 - LIGHTING SYSTEMS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0184.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 10903221 | Ferrari Bolt - 10903221 | Superseded | Order 10903224 instead | |
| 14040514 | Ferrari Flanged Nut - 14040514 | Superseded | Order 13046011 instead | |
| 13046012 | Ferrari Nut - 13046012 | Superseded | Order 13046011 instead | |
| 15896214 | Ferrari Nut M6 x 5 - 15896214 | Superseded | Order 14039614 instead | |
| 192623 | Ferrari Screw - 192623 | $5.40 | Special order, ships in 7-14 days | |
| 12601224 | Ferrari Washer - 12601224 | Superseded | Order 12601274 instead | |
| 12605370 | Ferrari Washer - 12605370 | Superseded | Order 12601274 instead | |
| 12605371 | Ferrari Washer - 12605371 | Superseded | Order 12601274 instead | |
| 680232 | Ferrari Washer - 680232 | Superseded | Order 12601274 instead | |
| 12605374 | Ferrari Wavy Washer - 12605374 | Superseded | Order 12601274 instead | |
| 1 | 343480 | Ferrari RH Headlamp - 343480 | $5,227.79 | Special order, ships in 7-14 days |
| 1 | 343487 | Ferrari RH Headlamp - 343487 | $6,399.26 | Special order, ships in 7-14 days |
| 1 | 343513 | Ferrari RH Headlamp - 343513 | $5,052.70 | Special order, ships in 7-14 days |
| 1 | 343517 | Ferrari RH Headlamp - 343517 | $6,399.26 | Special order, ships in 7-14 days |
| 1 | 343521 | Ferrari RH Headlamp - 343521 | $5,227.79 | Special order, ships in 7-14 days |
| 1 | 343556 | Ferrari RH Headlamp - 343556 | $6,399.26 | Special order, ships in 7-14 days |
| 2 | 343476 | Ferrari LH Headlamp - 343476 | $5,227.79 | Special order, ships in 7-14 days |
| 2 | 343484 | Ferrari LH Headlamp - 343484 | $6,399.26 | Special order, ships in 7-14 days |
| 2 | 343510 | Ferrari LH Headlamp - 343510 | $5,052.70 | Special order, ships in 7-14 days |
| 2 | 343515 | Ferrari LH Headlamp - 343515 | $6,399.26 | Special order, ships in 7-14 days |
| 2 | 343519 | Ferrari LH Headlamp - 343519 | $5,227.79 | Special order, ships in 7-14 days |
| 2 | 343523 | Ferrari LH Headlamp - 343523 | $6,399.26 | Special order, ships in 7-14 days |
| 3 | 343143 | Ferrari RH Fixed Taillight - 343143 | $1,291.30 | Special order, ships in 7-14 days |
| 3 | 343140 | Ferrari RH Fixed Taillight Unit - 343140 | $1,291.30 | Special order, ships in 7-14 days |
| 4 | 343139 | Ferrari LH Fixed Tail Light - 343139 | $1,291.30 | Special order, ships in 7-14 days |
| 4 | 343142 | Ferrari LH Fixed Taillight - 343142 | $1,291.30 | Special order, ships in 7-14 days |
| 5 | 317211 | Ferrari Lateral Turn Indicator - 317211 | $159.79 | Special order, ships in 7-14 days |
| 6 | 803566 | Ferrari Rear Brake Lamp - 803566 | $372.04 | Available, ships in 3-6 days |
| 7 | 334277 | Ferrari Rear Fog Light - 334277 | $415.82 | Special order, ships in 7-14 days |
| 8 | 808723 | Ferrari Plafoniera Anteriore Base - 808723 | $1,922.89 | Special order, ships in 7-14 days |
| 9 | 318013 | Ferrari Light Unit - 318013 | $61.45 | Special order, ships in 7-14 days |
| 10 | 10903224 | Ferrari Screw M6 x 40 - 10903224 | $0.50 | Available, ships in 3-6 days |
| 11 | 12625224 | Ferrari Washer - 12625224 | $0.13 | Available, ships in 3-6 days |
| 12 | 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days |
| 13 | 13046011 | Ferrari Flanged Nut - 13046011 | $0.73 | Available, ships in 3-6 days |
| 14 | 85834100 | Ferrari Screw M5 x 30 TBFTX - 85834100 | $0.79 | Special order, ships in 7-14 days |
| 15 | 12644401 | Ferrari Washer - 12644401 | $0.08 | Available, ships in 3-6 days |
| 16 | 10902324 | Ferrari Screw M6 x 18 - 10902324 | $0.27 | Available, ships in 3-6 days |
| 17 | 12601274 | Ferrari Wavy Washer 6mm - 12601274 | $1.04 | Available, ships in 3-6 days |
