Ferrari Portofino — Alternator (diagram 037)

Exploded view of the alternator on the Ferrari Portofino, with 22 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Portofino Alternator exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
1283531Ferrari Alternator - 283531$1,488.27Available, ships in 3-6 days
2299567Ferrari Alternator Brace Bracket - 299567$64.00Special order, ships in 7-14 days
3231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
414359524Ferrari Screw M8 x 80 - 14359524$0.52Special order, ships in 7-14 days
5178341Ferrari Washer - 178341$1.30Available, ships in 3-6 days
6248389Ferrari Bushing - 248389$12.88Available, ships in 3-6 days
711193874Ferrari Washer D.8.4-16x1.4 - 11193874$0.12Available, ships in 3-6 days
816102314Ferrari Nut M8 x 5 - 16102314$0.13Available, ships in 3-6 days
912601374Ferrari Wavy Washer 8mm - 12601374$3.12Available, ships in 3-6 days
10329269Ferrari Paratia Protezione Alternat - 329269$162.48Special order, ships in 7-14 days
11233600Ferrari/Maserati Screw - 233600$1.98In stock
16100825Ferrari Nut - 16100825SupersededOrder 16102314 instead
16102315Ferrari Nut - 16102315SupersededOrder 16102314 instead
16100821Ferrari Plain Nut 8mm x 6.25mm Pitch 1.25 - 16100821SupersededOrder 16102314 instead
16102311Ferrari RH Thread Nut - 16102311SupersededOrder 16102314 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
10615670Ferrari Washer - 10615670SupersededOrder 12601374 instead
10615671Ferrari Washer - 10615671SupersededOrder 12601374 instead
10615674Ferrari Washer - 10615674SupersededOrder 12601374 instead
10615679Ferrari Washer - 10615679SupersededOrder 12601374 instead
12601370Ferrari Washer - 12601370SupersededOrder 12601374 instead
12601379Ferrari Washer - 12601379SupersededOrder 12601374 instead
