Ferrari Portofino — External Gearbox Controls (diagram 041)
Exploded view of the external gearbox controls on the Ferrari Portofino, with 5 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 238370 | Ferrari Release Lever Complete - 238370 | $108.16 | Special order, ships in 7-14 days |
| 2 | 11066176 | Ferrari Seeger Ring D.13 - 11066176 | $0.08 | Available, ships in 3-6 days |
| 3 | 310524 | Ferrari Release Arm Mounting Bracket - 310524 | $127.82 | Special order, ships in 7-14 days |
| 4 | 243151 | Ferrari Screw M12 x 1.25 - 243151 | $11.56 | Special order, ships in 7-14 days |
| 252661 | Ferrari Release Arm Mounting Bracket - 252661 | $124.81 | Special order, ships in 7-14 days |
