Ferrari Portofino — Driveshaft (diagram 046)
Exploded view of the driveshaft on the Ferrari Portofino, with 3 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 803357 | Ferrari Transmission Shaft - 803357 | $3,608.70 | Special order, ships in 7-14 days |
| 2 | 803108 | Ferrari Stapled Collar - 803108 | $15.51 | Special order, ships in 7-14 days |
| 3 | 803109 | Ferrari Stop Ring - 803109 | $15.51 | Special order, ships in 7-14 days |
