Ferrari Portofino — Engine Injection Control (diagram 049)
Exploded view of the engine injection control on the Ferrari Portofino, with 5 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 342591 | Ferrari Ignition ECU - 342591 | $2,553.69 | Special order, ships in 7-14 days |
| 2 | 313125 | Ferrari Ignition ECU - 313125 | $2,084.11 | Special order, ships in 7-14 days |
| 3 | 796637 | Ferrari Motronic ECU Mounting Bracket - 796637 | $39.37 | Special order, ships in 7-14 days |
| 4 | 332833 | Ferrari Screw - 332833 | $2.82 | Special order, ships in 7-14 days |
| 5 | 340221 | Ferrari Screw - 340221 | $1.59 | Special order, ships in 7-14 days |
