Ferrari Purosangue — [ENGINE] - B.18 - FUEL PUMPS (diagram 0023)

Exploded view of the [engine] - b.18 - fuel pumps on the Ferrari Purosangue, with 15 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Purosangue [ENGINE] - B.18 - FUEL PUMPS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
331303Ferrari LH Fuel Pump - 331303Price on requestContact us for price and availability
793016Ferrari LH Fuel Pump - 793016$1,087.88Special order, ships in 7-14 days
331302Ferrari RH Fuel Pump - 331302SupersededOrder 815913 instead
793015Ferrari RH Fuel Pump - 793015SupersededOrder 815913 instead
1815913Ferrari RH Fuel Pump - 815913$1,092.79Special order, ships in 7-14 days
2815914Ferrari LH Fuel Pump - 815914$1,092.79Special order, ships in 7-14 days
3331787Ferrari HIGH PRESSURE PUMP CAM FOLLOWER - 331787$105.70Special order, ships in 7-14 days
414306434Ferrari Screw M8x25 - 14306434$0.71Special order, ships in 7-14 days
512638524Ferrari Flat Washer 8.15x15x1.5 - 12638524$0.12Available, ships in 3-6 days
6881951Ferrari RH Gdi Pump Soundproofing - 881951$127.82Special order, ships in 7-14 days
7881952Ferrari LH Gdi Pump Soundproofing - 881952$127.82Special order, ships in 7-14 days
8334138Ferrari RH Fuel Pipe - 334138$295.03Special order, ships in 7-14 days
9334139Ferrari Tubo Benzina Alta P.Pompa-Ra - 334139$295.03Special order, ships in 7-14 days
10341730Ferrari Fuel Pipe Fastener Bracket - 341730$81.11Special order, ships in 7-14 days
11231627Ferrari Screw M8 x 16 - 231627$1.25Available, ships in 3-6 days
