Ferrari Purosangue — [ENGINE] - B.33 - ALTERNATOR DRIVE (diagram 0038)
Exploded view of the [engine] - b.33 - alternator drive on the Ferrari Purosangue, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [ENGINE] - B.33 - ALTERNATOR DRIVE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0038.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14307724 | Ferrari Screw - 14307724 | $3.47 | Special order, ships in 7-14 days | |
| 1 | 919627 | Ferrari Belt - 919627 | $151.00 | Available, ships in 3-6 days |
| 2 | 272554 | Ferrari Smooth Pulley - 272554 | $369.30 | Special order, ships in 7-14 days |
| 3 | 14307721 | Ferrari Screw - 14307721 | $2.61 | Special order, ships in 7-14 days |
| 4 | 295763 | Ferrari Fixed Mule Pulley - 295763 | $90.95 | Special order, ships in 7-14 days |
| 5 | 271881 | Ferrari/Maserati Accessory Belt Tensioner - 271881 | $193.38 | In stock |
| 6 | 16044431 | Ferrari Bolt - 16044431 | $1.00 | In stock |
| 7 | 11193874 | Ferrari Washer D.8.4-16x1.4 - 11193874 | $0.12 | Available, ships in 3-6 days |
| 8 | 919628 | Ferrari Ancillary Drive Belt - 919628 | $241.27 | Special order, ships in 7-14 days |
| 9 | 14306424 | Ferrari Screw M8 x 25mm - 14306424 | Superseded | Order 14306421 instead |
| 10 | 258597 | Ferrari Plate - 258597 | $16.83 | Available, ships in 3-6 days |
| 11 | 257942 | Ferrari 6 Groove Pulley - 257942 | $344.69 | Special order, ships in 7-14 days |
