Ferrari Purosangue — [MECHANICAL SYSTEM] - D.7 - EXHAUST MANIFOLD (diagram 0056)
Exploded view of the [mechanical system] - d.7 - exhaust manifold on the Ferrari Purosangue, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [MECHANICAL SYSTEM] - D.7 - EXHAUST MANIFOLD exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0056.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 1 | 912452 | Ferrari RH Exhaust Manifold - 912452 | $8,615.56 | Special order, ships in 7-14 days |
| 2 | 912453 | Ferrari LH Exhaust Manifold - 912453 | $8,615.56 | Special order, ships in 7-14 days |
| 3 | 212702 | Ferrari Exhaust Manifold Gasket - 212702 | $13.60 | In stock |
| 4 | 888232 | Ferrari RH Rear Manifold Shield - 888232 | $517.04 | Special order, ships in 7-14 days |
| 5 | 888234 | Ferrari LH Rear Manifold Shield - 888234 | $418.56 | Special order, ships in 7-14 days |
| 6 | 888231 | Ferrari RH Front Manifold Shield - 888231 | $369.30 | Special order, ships in 7-14 days |
| 7 | 888233 | Ferrari LH Front Manifold Shield - 888233 | $241.27 | Special order, ships in 7-14 days |
| 8 | 210971 | Ferrari Copper Exhaust Nut - 210971 | $3.25 | In stock |
| 9 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 10 | 11628424 | Ferrari Screw 6X14 - 11628424 | $1.28 | Special order, ships in 7-14 days |
| 11 | 12647604 | Ferrari Washer - 12647604 | $0.12 | Available, ships in 3-6 days |
