Ferrari Purosangue — [MECHANICAL SYSTEM] - D.12 - TANK MOUNTS (diagram 0062)
Exploded view of the [mechanical system] - d.12 - tank mounts on the Ferrari Purosangue, with 9 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [MECHANICAL SYSTEM] - D.12 - TANK MOUNTS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0062.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 852525 | Ferrari Compl. RH Front Retainer For - 852525 | $160.02 | Special order, ships in 7-14 days |
| 2 | 852520 | Ferrari Compl. LH Front Retainer For - 852520 | $160.02 | Special order, ships in 7-14 days |
| 3 | 862015 | Ferrari Compl. Rear Retainer - 862015 | $103.38 | Special order, ships in 7-14 days |
| 4 | 853045 | Ferrari Tank Heat Shield - 853045 | $615.54 | Special order, ships in 7-14 days |
| 5 | 862024 | Ferrari RH Lateral Shield Mount - 862024 | $39.37 | Special order, ships in 7-14 days |
| 6 | 862023 | Ferrari LH Lateral Shield Mount - 862023 | $39.37 | Special order, ships in 7-14 days |
| 7 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 8 | 83222200 | Ferrari Fastener Button - 83222200 | $1.42 | Available, ships in 3-6 days |
| 9 | 792394 | Ferrari Screw TE M6 x 18 - 792394 | $0.84 | Available, ships in 3-6 days |
