Ferrari Purosangue — [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK (diagram 0065)
Exploded view of the [mechanical system] - d.15 - expansion tank on the Ferrari Purosangue, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0065.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 262111 | Ferrari Screw Collar - 262111 | $3.03 | Special order, ships in 7-14 days | |
| 12643711 | Ferrari Washer - 12643711 | Superseded | Order 12643724 instead | |
| 12643721 | Ferrari Washer - 12643721 | Superseded | Order 12643724 instead | |
| 14499301 | Ferrari Washer - 14499301 | Superseded | Order 12643724 instead | |
| 1 | 811963 | Ferrari Compl. Expansion Tank - 811963 | $517.04 | Special order, ships in 7-14 days |
| 2 | 780377 | Ferrari Compl. Header Tank Vent Pipe - 780377 | $984.88 | Special order, ships in 7-14 days |
| 3 | 888064 | Ferrari Compl. Engine Side Header Ta - 888064 | $467.80 | Special order, ships in 7-14 days |
| 4 | 813008 | Ferrari Compl. Radiator Side Breathe - 813008 | $103.38 | Special order, ships in 7-14 days |
| 5 | 254717 | Ferrari Screw M6 x 142 - 254717 | $7.86 | Available, ships in 3-6 days |
| 6 | 12643724 | Ferrari/Maserati Washer - 12643724 | $0.20 | In stock |
| 7 | 262559 | Ferrari Clip - 262559 | $1.78 | Available, ships in 3-6 days |
| 8 | 10397380 | Ferrari Ring - 10397380 | $2.82 | Available, ships in 3-6 days |
| 9 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 10 | 13125470 | Ferrari Collar - 13125470 | Superseded | Order 13126970 instead |
| 11 | 13126970 | Ferrari Collar - 13126970 | $3.03 | Available, ships in 3-6 days |
| 12 | 145030 | Ferrari Radiator Cap - 145030 | $89.98 | In stock |
| 13 | 812048 | Ferrari RUBBER HEADER TANK FILLER PIPE - 812048 | $342.66 | Special order, ships in 7-14 days |
| 14 | 262112 | Ferrari Collar - 262112 | Superseded | Order 262111 instead |
| 15 | 776476 | Ferrari RUBBER PIPE - 776476 | Price on request | Contact us for price and availability |
