Ferrari Purosangue — [MECHANICAL SYSTEM] - D.18 - LIFTING THE VEHICLE (diagram 0068)
Exploded view of the [mechanical system] - d.18 - lifting the vehicle on the Ferrari Purosangue, with 43 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [MECHANICAL SYSTEM] - D.18 - LIFTING THE VEHICLE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0068.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 328447 | Ferrari Electric Pump - 328447 | Superseded | Order 844229 instead | |
| 13046011 | Ferrari Flanged Nut - 13046011 | $0.73 | Available, ships in 3-6 days | |
| 15896214 | Ferrari Nut M6 x 5 - 15896214 | Superseded | Order 14039614 instead | |
| 255049 | Ferrari Screw 10x1.5x32 - 255049 | Superseded | Order 304224 instead | |
| 1 | 844229 | Ferrari Electric Pump - 844229 | $6,211.92 | Special order, ships in 7-14 days |
| 2 | 914563 | Ferrari Compl. Lift Pump Mounting Br - 914563 | $206.81 | Special order, ships in 7-14 days |
| 3 | 304224 | Ferrari Screw 10x1.5x28 - 304224 | $30.57 | Special order, ships in 7-14 days |
| 4 | 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days |
| 5 | 234285 | Ferrari Clip - 234285 | $1.40 | Available, ships in 3-6 days |
| 6 | 904119 | Ferrari Lift System Pipe Rear Section - 904119 | $295.43 | Special order, ships in 7-14 days |
| 7 | 264740 | Ferrari Plug 40x24mm - 264740 | $1.53 | Special order, ships in 7-14 days |
| 8 | 255047 | Ferrari Grommet - 255047 | $7.40 | Available, ships in 3-6 days |
| 9 | 255048 | Ferrari Grommet Shim - 255048 | $5.65 | Special order, ships in 7-14 days |
| 10 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 11 | 13578305 | Ferrari Washer - 13578305 | $0.17 | Available, ships in 3-6 days |
| 12 | 210246 | Ferrari Screw 8x25 - 210246 | $2.82 | Available, ships in 3-6 days |
| 13 | 904120 | Ferrari Flow Divider Bracket - 904120 | $68.92 | Special order, ships in 7-14 days |
| 14 | 13577724 | Ferrari Washer - 13577724 | $3.68 | Special order, ships in 7-14 days |
| 15 | 14358924 | Ferrari Screw - 14358924 | $0.86 | Available, ships in 3-6 days |
| 16 | 904117 | Ferrari Pipe From Separator To Three - 904117 | $83.68 | Special order, ships in 7-14 days |
| 17 | 260390 | Ferrari Flow Separator - 260390 | $3,313.48 | Special order, ships in 7-14 days |
| 18 | 904116 | Ferrari Pipe From Three Way Distribu - 904116 | $132.94 | Special order, ships in 7-14 days |
| 19 | 904115 | Ferrari Pipe From Three Way Distribu - 904115 | $150.17 | Special order, ships in 7-14 days |
| 19 | 989845 | Ferrari Tub.Blocc.3 Vie-Sez.Ruota Po - 989845 | $160.02 | Special order, ships in 7-14 days |
| 20 | 832934 | Ferrari Clip - 832934 | $2.18 | Special order, ships in 7-14 days |
| 21 | 285319 | Ferrari Insulation - 285319 | $233.56 | Special order, ships in 7-14 days |
| 22 | 277168 | Ferrari Actuator Pipe - 277168 | $240.94 | Special order, ships in 7-14 days |
| 23 | 904118 | Ferrari Pipe From Pump To Flow Separ - 904118 | $83.68 | Special order, ships in 7-14 days |
| 24 | 225408 | Ferrari Cylindrical Bushing - 225408 | $12.99 | Special order, ships in 7-14 days |
| 25 | 269858 | Ferrari Distributor Block - 269858 | $66.45 | Available, ships in 3-6 days |
| 27 | 941219 | Ferrari Clip - 941219 | $3.47 | Special order, ships in 7-14 days |
| 28 | 941254 | Ferrari Pipe From Front Underbody Di - 941254 | $211.73 | Special order, ships in 7-14 days |
| 29 | 867970 | Ferrari Pipe From Engine Compartment - 867970 | $120.62 | Special order, ships in 7-14 days |
| 30 | 261587 | Ferrari Union - 261587 | $49.14 | Special order, ships in 7-14 days |
| 31 | 259638 | Ferrari Gasket 8.7-14 - 259638 | $21.60 | Special order, ships in 7-14 days |
| 32 | 817548 | Ferrari Pipe From Block To RH Front - 817548 | $100.93 | Special order, ships in 7-14 days |
| 33 | 817547 | Ferrari Pipe From Block To LH Front - 817547 | $108.31 | Special order, ships in 7-14 days |
| 34 | 258770 | Ferrari Pad - 258770 | $59.07 | Special order, ships in 7-14 days |
| 35 | 234284 | Ferrari Clip - 234284 | $1.23 | Available, ships in 3-6 days |
| 36 | 862001 | Ferrari Lift System Pipe - 862001 | $270.83 | Special order, ships in 7-14 days |
| 37 | 262737 | Ferrari Rubber Retainer - 262737 | $10.06 | Special order, ships in 7-14 days |
| 38 | 990806 | Ferrari Staffa Oggett. Tubo Sollev. - 990806 | $78.76 | Special order, ships in 7-14 days |
| 39 | 14040514 | Ferrari Flanged Nut - 14040514 | Superseded | Order 13046011 instead |
