Ferrari Purosangue — [MECHANICAL SYSTEM] - D.30.02 - STEERING WHEEL AND STEERING SYSTEM - STEERING WHEEL AND AIRBAG (diagram 0088)
Exploded view of the [mechanical system] - d.30.02 - steering wheel and steering system - steering wheel and airbag on the Ferrari Purosangue, with 32 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [MECHANICAL SYSTEM] - D.30.02 - STEERING WHEEL AND STEERING SYSTEM - STEERING WHEEL AND AIRBAG exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0088.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 105303 | Ferrari Clamp - 105303 | Superseded | Order 13000690 instead | |
| 12173990 | Ferrari Clip - 12173990 | Superseded | Order 13000690 instead | |
| 12174090 | Ferrari Hose Clip 32-50 - 12174090 | Superseded | Order 13000690 instead | |
| 12177090 | Ferrari Hose Clip 32-50 - 12177090 | Superseded | Order 13000690 instead | |
| 275398 | Ferrari Screw - 275398 | Superseded | Order 301723 instead | |
| 1 | 55062156 | Ferrari COMPL. STEERING WHEEL - 55062156 | $20,570.03 | Contact us to order |
| 1 | 55062162 | Ferrari COMPL. STEERING WHEEL - 55062162 | $30,957.17 | Contact us to order |
| 1 | 55062163 | Ferrari COMPL. STEERING WHEEL - 55062163 | Price on request | Contact us for price and availability |
| 1 | 55062164 | Ferrari COMPL. STEERING WHEEL - 55062164 | $30,079.54 | Contact us to order |
| 1 | 70008175 | Ferrari COMPL. STEERING WHEEL - 70008175 | $36,036.26 | Contact us to order |
| 1 | 855691 | Ferrari COMPL. STEERING WHEEL - 855691 | Price on request | Contact us for price and availability |
| 1 | 855694 | Ferrari Compl. Steering Wheel - 855694 | $35,747.72 | Contact us to order |
| 1 | 855697 | Ferrari Compl. Steering Wheel - 855697 | $29,510.22 | Contact us to order |
| 1 | 855699 | Ferrari Compl. Steering Wheel - 855699 | $39,215.49 | Contact us to order |
| 1 | 960488 | Ferrari COMPL. STEERING WHEEL - 960488 | Price on request | Contact us for price and availability |
| 1 | 960491 | Ferrari COMPL. STEERING WHEEL - 960491 | Price on request | Contact us for price and availability |
| 1 | 961417 | Ferrari Compl. Steering Wheel - 961417 | $39,447.64 | Contact us to order |
| 1 | 961419 | Ferrari Compl. Steering Wheel - 961419 | $39,447.64 | Contact us to order |
| 2 | 849389 | Ferrari Gruppo Com.Cambio Magnetic - 849389 | $2,627.38 | Special order, ships in 7-14 days |
| 2 | 70007216 | Ferrari Magnetic Gearbox Control Set - 70007216 | $3,109.78 | Special order, ships in 7-14 days |
| 2 | 70007218 | Ferrari Magnetic Gearbox Control Set - 70007218 | $6,111.88 | Special order, ships in 7-14 days |
| 2 | 70007219 | Ferrari Magnetic Gearbox Control Set - 70007219 | $23,337.74 | Special order, ships in 7-14 days |
| 2 | 817753 | Ferrari Magnetic Gearbox Control Set - 817753 | $5,880.06 | Special order, ships in 7-14 days |
| 3 | 309296 | Ferrari Steering Angle Sensor - 309296 | $371.53 | Special order, ships in 7-14 days |
| 4 | 301723 | Ferrari Screw - 301723 | $164.72 | Special order, ships in 7-14 days |
| 5 | 278791 | Ferrari Steering Column Shield - 278791 | $88.49 | Special order, ships in 7-14 days |
| 6 | 13000690 | Ferrari/Maserati Hose Clamp - 13000690 | $1.49 | In stock |
| 7 | 783230 | Ferrari Driver Side Airbag Module - 783230 | $1,852.54 | Special order, ships in 7-14 days |
| 8 | 786772 | Ferrari Washer - 786772 | $1.17 | Special order, ships in 7-14 days |
| 9 | 828380 | Ferrari Clock Spring Connector Spring - 828380 | $3.26 | Available, ships in 3-6 days |
| 10 | 828381 | Ferrari Clock Spring Connector Lock - 828381 | $12.21 | Available, ships in 3-6 days |
| 11 | 55032107 | Ferrari Compl. Steering Wheel LED Bar - 55032107 | $860.56 | Special order, ships in 7-14 days |
