Ferrari Purosangue — [VEHICLE TRIM] - E.3 - ROOF (diagram 0102)
Exploded view of the [vehicle trim] - e.3 - roof on the Ferrari Purosangue, with 21 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [VEHICLE TRIM] - E.3 - ROOF exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0102.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 870607 | Ferrari Complete Roof Panel - 870607 | $37,479.28 | Contact us to order |
| 1 | 919684 | Ferrari Complete Roof Panel - 919684 | $60,463.06 | Contact us to order |
| 1 | 973729 | Ferrari COMPLETE ROOF PANEL - 973729 | Price on request | Contact us to order |
| 1 | 869869 | Ferrari Roof Glass Panel - 869869 | Superseded | Order 955060752 instead |
| 1 | 955060752 | Ferrari Roof Glass Panel - 955060752 | $23,317.15 | Special order, ships in 7-14 days |
| 2 | 985822822 | Ferrari Compl. Roof Trim - 985822822 | $5,215.29 | Special order, ships in 7-14 days |
| 3 | 914537 | Ferrari Screw - 914537 | $3.26 | Special order, ships in 7-14 days |
| 4 | 816549 | Ferrari Compl. Rear Roof Beam - 816549 | $1,649.69 | Special order, ships in 7-14 days |
| 5 | 985816548 | Ferrari Compl. Rear Roof Cross Membe - 985816548 | $837.14 | Special order, ships in 7-14 days |
| 6 | 779513 | Ferrari Compl. Centre Roof Closure E - 779513 | Superseded | Order 994750 instead |
| 6 | 994750 | Ferrari Compl. Centre Roof Closure E - 994750 | $108.31 | Special order, ships in 7-14 days |
| 7 | 779507 | Ferrari Compl. RH Lateral Roof Closu - 779507 | $194.48 | Special order, ships in 7-14 days |
| 7 | 994749 | Ferrari Compl. RH Lateral Roof Closu - 994749 | $68.92 | Special order, ships in 7-14 days |
| 8 | 779508 | Ferrari Compl. LH Lateral Roof Closu - 779508 | Superseded | Order 994748 instead |
| 8 | 994748 | Ferrari Compl. LH Lateral Roof Closu - 994748 | $66.45 | Special order, ships in 7-14 days |
| 9 | 985816544 | Ferrari Compl. Upper Windscreen Cros - 985816544 | $1,698.93 | Special order, ships in 7-14 days |
| 10 | 812752 | Ferrari Screw - 812752 | $11.14 | Special order, ships in 7-14 days |
| 11 | 12642024 | Ferrari Washer - 12642024 | Superseded | Order 12642021 instead |
| 12 | 911976 | Ferrari Wide Flange Hex Nut - 911976 | $24.02 | Special order, ships in 7-14 days |
| 13 | 12646727 | Ferrari Washer D. 8.45 X 20 X 2 - 12646727 | $0.40 | Available, ships in 3-6 days |
| 14 | 86004700 | Ferrari Clip - 86004700 | $1.44 | Special order, ships in 7-14 days |
