Ferrari Purosangue — [VEHICLE TRIM] - E.16 - REAR SHIELDS (diagram 0119)
Exploded view of the [vehicle trim] - e.16 - rear shields on the Ferrari Purosangue, with 9 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [VEHICLE TRIM] - E.16 - REAR SHIELDS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0119.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 16043430 | Ferrari Bolt - 16043430 | Superseded | Order 16043434 instead | |
| 16043431 | Ferrari Screw - 16043431 | Superseded | Order 16043434 instead | |
| 1 | 841056 | Ferrari Compl. Rear Flat Undertray - 841056 | $1,329.59 | Contact us to order |
| 2 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 3 | 16043434 | Ferrari Screw M8 x 20 - 16043434 | $0.40 | Available, ships in 3-6 days |
| 4 | 12642024 | Ferrari Washer - 12642024 | Superseded | Order 12642021 instead |
| 5 | 11194074 | Ferrari Washer 8.6-16x1.9 - 11194074 | $0.08 | Available, ships in 3-6 days |
| 6 | 880370 | Ferrari LH Rear Flat Undertray - 880370 | $44.29 | Available, ships in 3-6 days |
| 7 | 880371 | Ferrari RH Rear Flat Undertray - 880371 | $44.29 | Available, ships in 3-6 days |
