Ferrari Purosangue — [VEHICLE TRIM] - E.17 - FRONT WHEELHOUSE (diagram 0120)
Exploded view of the [vehicle trim] - e.17 - front wheelhouse on the Ferrari Purosangue, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [VEHICLE TRIM] - E.17 - FRONT WHEELHOUSE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0120.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12643711 | Ferrari Washer - 12643711 | Superseded | Order 12643724 instead | |
| 12643721 | Ferrari Washer - 12643721 | Superseded | Order 12643724 instead | |
| 14499301 | Ferrari Washer - 14499301 | Superseded | Order 12643724 instead | |
| 1 | 906021 | Ferrari Compl. RH Front WheeLHouse - 906021 | Superseded | Order 996837 instead |
| 1 | 996837 | Ferrari Compl. RH Front WheeLHouse - 996837 | $1,094.32 | Special order, ships in 7-14 days |
| 2 | 906020 | Ferrari Compl. LH Front WheeLHouse - 906020 | Superseded | Order 996840 instead |
| 2 | 996840 | Ferrari Compl. LH Front WheeLHouse - 996840 | $1,094.32 | Special order, ships in 7-14 days |
| 3 | 84247400 | Ferrari Female Clip - 84247400 | $2.59 | Available, ships in 3-6 days |
| 4 | 84247300 | Ferrari Male Clip - 84247300 | $2.82 | Available, ships in 3-6 days |
| 5 | 82362500 | Ferrari Screw - 82362500 | $1.49 | Available, ships in 3-6 days |
| 6 | 82113500 | Ferrari Screw Torx M6 x 18 with Washer D. 15 - 82113500 | $5.86 | Available, ships in 3-6 days |
| 7 | 83222200 | Ferrari Fastener Button - 83222200 | $1.42 | Available, ships in 3-6 days |
| 8 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 9 | 993135 | Ferrari Staffa Fiss Mcm Anteriore Dx - 993135 | $130.47 | Special order, ships in 7-14 days |
| 10 | 996029 | Ferrari Staffa Supporto Mcm Ant Dx C - 996029 | $125.54 | Special order, ships in 7-14 days |
| 11 | 16296934 | Ferrari Screw 6x14 - 16296934 | $0.90 | Special order, ships in 7-14 days |
| 12 | 16286121 | Ferrari Screw M6 x 20 - 16286121 | $1.23 | Available, ships in 3-6 days |
| 13 | 12643724 | Ferrari/Maserati Washer - 12643724 | $0.20 | In stock |
| 14 | 14065921 | Ferrari Flanged Nut - 14065921 | $0.50 | Available, ships in 3-6 days |
| 15 | 88187400 | Ferrari Spessore Di Regolaz.Ant. Sp. - 88187400 | $8.82 | Special order, ships in 7-14 days |
