Ferrari Purosangue — [VEHICLE TRIM] - E.22 - FRONT AIR INTAKES (diagram 0125)
Exploded view of the [vehicle trim] - e.22 - front air intakes on the Ferrari Purosangue, with 9 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [VEHICLE TRIM] - E.22 - FRONT AIR INTAKES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0125.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 880403 | Ferrari Compl. RH Brake Air Duct - 880403 | $233.89 | Special order, ships in 7-14 days |
| 2 | 880406 | Ferrari Compl. LH Brake Air Duct - 880406 | $233.89 | Special order, ships in 7-14 days |
| 3 | 880372 | Ferrari Compl. RH Ptu Radiator Duct - 880372 | $369.30 | Special order, ships in 7-14 days |
| 4 | 880444 | Ferrari Compl. LH Duct For Suspension Oil Radiator - 880444 | $418.56 | Special order, ships in 7-14 days |
| 5 | 82115900 | Ferrari Screw M6 x 14 With Washer - 82115900 | $1.23 | Available, ships in 3-6 days |
| 6 | 82113500 | Ferrari Screw Torx M6 x 18 with Washer D. 15 - 82113500 | $5.86 | Available, ships in 3-6 days |
| 7 | 81591700 | Ferrari Screw TE M6 x 18 with washer - 81591700 | $4.12 | Available, ships in 3-6 days |
| 8 | 84247400 | Ferrari Female Clip - 84247400 | $2.59 | Available, ships in 3-6 days |
| 9 | 83222200 | Ferrari Fastener Button - 83222200 | $1.42 | Available, ships in 3-6 days |
