Ferrari Purosangue — [VEHICLE TRIM] - E.23 - LATERAL AIR INTAKES (diagram 0126)
Exploded view of the [vehicle trim] - e.23 - lateral air intakes on the Ferrari Purosangue, with 21 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [VEHICLE TRIM] - E.23 - LATERAL AIR INTAKES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0126.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 799942 | Ferrari Compl. Inlet Tray - 799942 | $664.78 | Special order, ships in 7-14 days |
| 1 | 880730 | Ferrari Compl. Inlet Tray - 880730 | $590.91 | Special order, ships in 7-14 days |
| 2 | 880637 | Ferrari Compl. LH Fender Duct - 880637 | $295.43 | Special order, ships in 7-14 days |
| 2 | 880662 | Ferrari Compl. RH Fender Duct - 880662 | $295.43 | Special order, ships in 7-14 days |
| 3 | 750060 | Ferrari Compl. Tub Cover - 750060 | $320.06 | Special order, ships in 7-14 days |
| 3 | 810581 | Ferrari Compl. Tub Cover - 810581 | $369.30 | Special order, ships in 7-14 days |
| 4 | 880754 | Ferrari Upper Battery Bracket - 880754 | $140.32 | Special order, ships in 7-14 days |
| 5 | 880762 | Ferrari Battery Tie-Rod - 880762 | $34.44 | Special order, ships in 7-14 days |
| 6 | 817246 | Ferrari Compl. Battery Carrier Plate - 817246 | $320.06 | Special order, ships in 7-14 days |
| 6 | 880767 | Ferrari Compl. Battery Carrier Plate - 880767 | $270.83 | Special order, ships in 7-14 days |
| 7 | 799951 | Ferrari Compl. Air Conditioning Tray - 799951 | $640.17 | Special order, ships in 7-14 days |
| 7 | 900135 | Ferrari Compl. Air Conditioning Tray - 900135 | $615.54 | Special order, ships in 7-14 days |
| 8 | 14040614 | Ferrari Flanged Nut 6mm - 14040614 | $0.27 | Available, ships in 3-6 days |
| 9 | 68888400 | Ferrari Rivet - 68888400 | $5.04 | Available, ships in 3-6 days |
| 10 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 11 | 82115900 | Ferrari Screw M6 x 14 With Washer - 82115900 | $1.23 | Available, ships in 3-6 days |
| 12 | 781953 | Ferrari Screw - 781953 | $2.59 | Special order, ships in 7-14 days |
| 13 | 256490 | Ferrari Screw TBEI M5 x 16 - 256490 | $3.91 | Available, ships in 3-6 days |
| 14 | 228265 | Ferrari Nut 6x1x9 - 228265 | $0.40 | Available, ships in 3-6 days |
| 15 | 792394 | Ferrari Screw TE M6 x 18 - 792394 | $0.84 | Available, ships in 3-6 days |
| 16 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
