Ferrari Purosangue — [VEHICLE TRIM] - E.33 - FRONT LID TRIM (diagram 0141)
Exploded view of the [vehicle trim] - e.33 - front lid trim on the Ferrari Purosangue, with 16 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [VEHICLE TRIM] - E.33 - FRONT LID TRIM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0141.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 63402800 | Ferrari Ball Pin - 63402800 | Superseded | Order 85216400 instead | |
| 69205900 | Ferrari Ball Pin - 69205900 | Superseded | Order 85216400 instead | |
| 64577200 | Ferrari Pin - 64577200 | Superseded | Order 85216400 instead | |
| 65939900 | Ferrari Pin - 65939900 | Superseded | Order 85216400 instead | |
| 1 | 748192 | Ferrari Compl. Engine Compartment Li - 748192 | $664.78 | Special order, ships in 7-14 days |
| 2 | 885585 | Ferrari Compl. RH Headlamp Lid Bezel - 885585 | $169.87 | Special order, ships in 7-14 days |
| 3 | 885584 | Ferrari Compl. LH Headlamp Lid Bezel - 885584 | $169.87 | Special order, ships in 7-14 days |
| 4 | 859800 | Ferrari Screw - 859800 | $0.86 | Special order, ships in 7-14 days |
| 5 | 85216400 | Ferrari Pin - 85216400 | $2.98 | In stock |
| 6 | 14591687 | Ferrari Fixing Button - 14591687 | $0.13 | Available, ships in 3-6 days |
| 7 | 774624 | Ferrari Compl. RH Front Lid Air Duct - 774624 | $615.54 | Special order, ships in 7-14 days |
| 8 | 774615 | Ferrari Compl. LH Front Lid Air Duct - 774615 | $615.54 | Special order, ships in 7-14 days |
| 9 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 9 | 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days |
| 10 | 856582 | Ferrari Spacer Block - 856582 | $125.37 | Available, ships in 3-6 days |
| 11 | 949856 | Ferrari Gas Strut - 949856 | $80.96 | Special order, ships in 7-14 days |
