Ferrari Purosangue — [VEHICLE TRIM] - E.34 - FRONT LID LOCK (diagram 0142)
Exploded view of the [vehicle trim] - e.34 - front lid lock on the Ferrari Purosangue, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [VEHICLE TRIM] - E.34 - FRONT LID LOCK exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0142.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 84076100 | Ferrari Engine Compartment Lid Lock - 84076100 | $216.66 | Special order, ships in 7-14 days |
| 2 | 14304428 | Ferrari Screw - 14304428 | $0.59 | Special order, ships in 7-14 days |
| 3 | 885588 | Ferrari Compl. Bowden Cable - 885588 | $443.17 | Special order, ships in 7-14 days |
| 3 | 889111 | Ferrari Compl. Bowden Cable - 889111 | $443.17 | Special order, ships in 7-14 days |
| 4 | 80246800 | Ferrari Striker Plate - 80246800 | $93.40 | Special order, ships in 7-14 days |
| 5 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 6 | 81923100 | Ferrari Screw - 81923100 | $1.15 | Available, ships in 3-6 days |
| 7 | 234285 | Ferrari Clip - 234285 | $1.40 | Available, ships in 3-6 days |
| 8 | 13046112 | Ferrari Nut - 13046112 | $0.46 | Available, ships in 3-6 days |
| 9 | 12647878 | Ferrari Washer - 12647878 | $5.65 | Special order, ships in 7-14 days |
