Ferrari Purosangue — [VEHICLE TRIM] - E.55 - WIPERS AND HEADLAMP WASHERS (diagram 0174)
Exploded view of the [vehicle trim] - e.55 - wipers and headlamp washers on the Ferrari Purosangue, with 41 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [VEHICLE TRIM] - E.55 - WIPERS AND HEADLAMP WASHERS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0174.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 106853 | Ferrari Spring Washer 10mm - 106853 | Superseded | Order 12601474 instead | |
| 10516873 | Ferrari Washer - 10516873 | Superseded | Order 12601474 instead | |
| 12601471 | Ferrari Washer - 12601471 | Superseded | Order 12601474 instead | |
| 12640606 | Ferrari Washer - 12640606 | Superseded | Order 12640678 instead | |
| 12640608 | Ferrari Washer - 12640608 | Superseded | Order 12640678 instead | |
| 12640677 | Ferrari Washer - 12640677 | Superseded | Order 12640678 instead | |
| 1 | 881971 | Ferrari Compl. Windscreen Washer Res - 881971 | $664.78 | Special order, ships in 7-14 days |
| 2 | 881955 | Ferrari Compl. Windscreen Washer Res - 881955 | $295.43 | Special order, ships in 7-14 days |
| 3 | 881973 | Ferrari Windscreen Washer Pipe - 881973 | $135.39 | Special order, ships in 7-14 days |
| 4 | 84093700 | Ferrari Clip - 84093700 | $2.82 | Special order, ships in 7-14 days |
| 5 | 881977 | Ferrari Compl. Rear Bracket Of Wiper - 881977 | $66.45 | Special order, ships in 7-14 days |
| 6 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 7 | 907489 | Ferrari Compl. Front Fastener Bracke - 907489 | $98.46 | Special order, ships in 7-14 days |
| 8 | 982887 | Ferrari Hydraulic Connector - 982887 | $21.64 | Special order, ships in 7-14 days |
| 9 | 814563 | Ferrari Windscreen Wiper Assembly - 814563 | $1,600.44 | Special order, ships in 7-14 days |
| 9 | 881976 | Ferrari Windscreen Wiper Assembly - 881976 | $1,477.33 | Special order, ships in 7-14 days |
| 10 | 749212 | Ferrari Compl. Wiper Mounting Bracke - 749212 | $113.24 | Special order, ships in 7-14 days |
| 10 | 881965 | Ferrari Compl. Wiper Mounting Bracke - 881965 | $93.53 | Special order, ships in 7-14 days |
| 11 | 10903034 | Ferrari Screw 6x35 - 10903034 | $0.82 | Available, ships in 3-6 days |
| 12 | 12640678 | Ferrari Washer 6.15x25x2 - 12640678 | $3.47 | Available, ships in 3-6 days |
| 13 | 81591700 | Ferrari Screw TE M6 x 18 with washer - 81591700 | $4.12 | Available, ships in 3-6 days |
| 14 | 745887 | Ferrari Compl. Passenger Side Wiper Arm & Blade - LHD - 745887 | $415.82 | Available, ships in 3-6 days |
| 14 | 749168 | Ferrari Compl. Passenger Side Wiper Arm & Blade - RHD - 749168 | $503.37 | Available, ships in 3-6 days |
| 15 | 745886 | Ferrari Compl. Driver Side Wiper Arm & Blade - LHD - 745886 | $437.71 | Available, ships in 3-6 days |
| 15 | 749191 | Ferrari Compl. Driver Side Wiper Arm & Blade - RHD - 749191 | $525.26 | Available, ships in 3-6 days |
| 16 | 15811787 | Ferrari Protective Cap 17 x 10.5 - 15811787 | $1.53 | Available, ships in 3-6 days |
| 17 | 10791021 | Ferrari Nut LHD - 10791021 | $1.25 | Available, ships in 3-6 days |
| 18 | 12601474 | Ferrari Wavy Washer 10mm - 12601474 | $0.06 | Available, ships in 3-6 days |
| 19 | 742289 | Ferrari Upper Cover Of Driver Side W - 742289 | $17.46 | Special order, ships in 7-14 days |
| 19 | 749077 | Ferrari Upper Cover Of Driver Side Windscreen Wiper - 749077 | $17.21 | Special order, ships in 7-14 days |
| 20 | 742286 | Ferrari Lower Cover Of Driver Side W - 742286 | $16.46 | Special order, ships in 7-14 days |
| 20 | 749076 | Ferrari Lower Cover Of Driver Side Windscreen Wiper - 749076 | $16.00 | Special order, ships in 7-14 days |
| 21 | 881962 | Ferrari Passenger Side Windscreen Wiper Blade - LHD - 881962 | $192.57 | Available, ships in 3-6 days |
| 21 | 814895 | Ferrari Passenger Side Windscreen Wiper Blade - RHD - 814895 | $240.73 | Available, ships in 3-6 days |
| 22 | 881970 | Ferrari Driver Side Windscreen Wiper Blade - LHD - 881970 | $192.57 | Available, ships in 3-6 days |
| 22 | 814863 | Ferrari Passenger Side Windscreen Wiper Blade - RHD - 814863 | $240.73 | Available, ships in 3-6 days |
| 23 | 82198600 | Ferrari Filler Pipe Seal - 82198600 | $44.24 | Special order, ships in 7-14 days |
| 24 | 81633100 | Ferrari Fluid Level Sensor - 81633100 | $240.39 | Special order, ships in 7-14 days |
| 25 | 81633200 | Ferrari Gasket - 81633200 | $50.24 | Special order, ships in 7-14 days |
| 26 | 81632900 | Ferrari Windscreen Washer Pump - 81632900 | $172.84 | Available, ships in 3-6 days |
| 27 | 65511700 | Ferrari Seal For Washer Pump - 65511700 | $9.81 | Available, ships in 3-6 days |
