Ferrari Purosangue — [ELECTRICAL SYSTEM] - F.1 - BATTERIES (diagram 0184)
Exploded view of the [electrical system] - f.1 - batteries on the Ferrari Purosangue, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [ELECTRICAL SYSTEM] - F.1 - BATTERIES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0184.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 341745 | Ferrari Tubo Sfiato Batteriaf164 Vas - 341745 | Superseded | Order 815156 instead | |
| 1 | 326782 | Ferrari Battery 80Ah - 326782 | $830.51 | Available, ships in 3-6 days |
| 2 | 820595 | Ferrari Part Search Results - 820595 | $344.21 | Special order, ships in 7-14 days |
| 3 | 801846 | Ferrari Battery Sensor - 801846 | $262.24 | Special order, ships in 7-14 days |
| 4 | 199631 | Ferrari Union - 199631 | $0.82 | Available, ships in 3-6 days |
| 5 | 815156 | Ferrari Battery Breather Pipe - 815156 | $41.76 | Special order, ships in 7-14 days |
