Ferrari Purosangue — [ELECTRICAL SYSTEM] - F.3 - INSTRUMENTATION (diagram 0186)
Exploded view of the [electrical system] - f.3 - instrumentation on the Ferrari Purosangue, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [ELECTRICAL SYSTEM] - F.3 - INSTRUMENTATION exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0186.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 1 | 55016571 | Ferrari Instrument Panel - 55016571 | $19,370.75 | Contact us to order |
| 1 | 55016572 | Ferrari Instrument Panel - 55016572 | $19,968.23 | Contact us to order |
| 1 | 811598 | Ferrari Instrument Panel - 811598 | Superseded | Order 55016571 instead |
| 1 | 811599 | Ferrari Instrument Panel - 811599 | $19,968.23 | Contact us to order |
| 2 | 55003064 | Ferrari Head Up Display - 55003064 | $5,944.59 | Special order, ships in 7-14 days |
| 2 | 55003066 | Ferrari Head Up Display - 55003066 | Superseded | Order 942885 instead |
| 2 | 869718 | Ferrari Head Up Display - 869718 | Superseded | Order 55003064 instead |
| 2 | 942884 | Ferrari Head Up Display - 942884 | Superseded | Order 55003064 instead |
| 2 | 942885 | Ferrari Head Up Display - 942885 | $5,944.59 | Special order, ships in 7-14 days |
| 3 | 883403 | Ferrari Fixing and Centering Screw - 883403 | $28.39 | Special order, ships in 7-14 days |
| 4 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
