Ferrari Purosangue — [ELECTRICAL SYSTEM] - F.11 - ANTI-THEFT SYSTEM (diagram 0194)
Exploded view of the [electrical system] - f.11 - anti-theft system on the Ferrari Purosangue, with 31 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Purosangue [ELECTRICAL SYSTEM] - F.11 - ANTI-THEFT SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/purosangue/0194.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 332825 | Ferrari Glonass Speaker - 332825 | $78.66 | Special order, ships in 7-14 days |
| 2 | 294011 | Ferrari Slave Dipole Sensor - 294011 | $437.71 | Special order, ships in 7-14 days |
| 4 | 333337 | Ferrari Gsm Microphone - 333337 | $319.62 | Special order, ships in 7-14 days |
| 5 | 886985 | Ferrari Ecall Node - 886985 | $3,494.05 | Special order, ships in 7-14 days |
| 5 | 886989 | Ferrari Ecall Node - 886989 | $3,494.05 | Special order, ships in 7-14 days |
| 5 | 886990 | Ferrari Ecall Node - 886990 | $3,494.05 | Special order, ships in 7-14 days |
| 5 | 818431 | Ferrari GLONASS ECU - 818431 | Price on request | Contact us for price and availability |
| 6 | 824398 | Ferrari RF Antenna For Svr - 824398 | $72.10 | Special order, ships in 7-14 days |
| 7 | 336506 | Ferrari Glonass Gps Antenna - 336506 | $102.69 | Special order, ships in 7-14 days |
| 8 | 336507 | Ferrari Glonass Gsm Antenna - 336507 | $102.69 | Special order, ships in 7-14 days |
| 9 | 293416 | Ferrari Master Dipole Anti-Lift Sensor - 293416 | $721.22 | Special order, ships in 7-14 days |
| 10 | 875982 | Ferrari Compl. Anti-Theft System Sir - 875982 | $284.11 | Special order, ships in 7-14 days |
| 10 | 336779 | Ferrari Compl. Anti-Theft System Siren - 336779 | $262.24 | Special order, ships in 7-14 days |
| 11 | 13046114 | Ferrari Flanged Nut - 13046114 | $0.31 | Available, ships in 3-6 days |
| 12 | 55011035 | Ferrari Wrench - 55011035 | $2,682.68 | Special order, ships in 7-14 days |
| 12 | 55011036 | Ferrari Wrench - 55011036 | $2,682.68 | Special order, ships in 7-14 days |
| 12 | 975825 | Ferrari Wrench Handle - 975825 | $2,682.68 | Special order, ships in 7-14 days |
| 12 | 975826 | Ferrari Wrench Handle - 975826 | $2,682.68 | Special order, ships in 7-14 days |
| 13 | 55080828 | Ferrari Key Fob - 55080828 | $565.49 | Available, ships in 3-6 days |
| 13 | 865295 | Ferrari Key Fob - 865295 | Superseded | Order 55080828 instead |
| 13 | 865703 | Ferrari Key Fob - 865703 | $1,475.26 | Special order, ships in 7-14 days |
| 13 | 923359 | Ferrari Key Fob - 923359 | $516.33 | Special order, ships in 7-14 days |
| 14 | 179318 | Ferrari Aluminium Spacer For Rad Fan - 179318 | $4.56 | Special order, ships in 7-14 days |
| 15 | 865301 | Ferrari Screw - Torx M 1.4 x 5 - 865301 | $1.44 | Available, ships in 3-6 days |
| 16 | 895549 | Ferrari Key Screwdriver-Ring Kit - 895549 | $368.79 | Special order, ships in 7-14 days |
| 17 | 824397 | Ferrari Driver Card For Svr - 824397 | $491.74 | Special order, ships in 7-14 days |
| 19 | 811665 | Ferrari Key And Block Kit - 811665 | $1,450.67 | Special order, ships in 7-14 days |
| 20 | 6326163 | Ferrari Secret Card Label For Keys - 6326163 | $4.39 | Special order, ships in 7-14 days |
| 21 | 865300 | Ferrari Key Ring - 865300 | $44.24 | Special order, ships in 7-14 days |
| 22 | 925517 | Ferrari Screwdriver Adapter - 925517 | $179.46 | Special order, ships in 7-14 days |
| 23 | 55019853 | Ferrari Siren Wiring Harness - 55019853 | $51.62 | Special order, ships in 7-14 days |
