Ferrari Roma Spider — [GEARBOX] - C.5 - CLUTCH HOUSING (diagram 0046)
Exploded view of the [gearbox] - c.5 - clutch housing on the Ferrari Roma Spider, with 31 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [GEARBOX] - C.5 - CLUTCH HOUSING exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0046.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 341029 | Ferrari Bushing Travel Stop Bracket - 341029 | $203.15 | Special order, ships in 7-14 days | |
| 806571 | Ferrari Clutch Housing Shaft - 806571 | Superseded | Order 338192 instead | |
| 806563 | Ferrari Compl. Transmission Housing - 806563 | Superseded | Order 866551 instead | |
| 14306621 | Ferrari Screw 8X35 - 14306621 | Superseded | Order 14306624 instead | |
| 13543121 | Ferrari Stud - 13543121 | Superseded | Order 13543124 instead | |
| 1 | 866551 | Ferrari Compl. Transmission Housing - 866551 | $2,623.79 | Special order, ships in 7-14 days |
| 2 | 338192 | Ferrari Clutch Housing Shaft - 338192 | $2,806.95 | Special order, ships in 7-14 days |
| 3 | 318975 | Ferrari Snap Ring - 318975 | $524.51 | Special order, ships in 7-14 days |
| 4 | 252524 | Ferrari Bearing Complete With Inner Race - 252524 | $1,349.58 | Special order, ships in 7-14 days |
| 5 | 253627 | Ferrari Containment Ring - 253627 | $393.38 | Special order, ships in 7-14 days |
| 6 | 11062474 | Ferrari Snap Ring - 11062474 | $10.46 | Available, ships in 3-6 days |
| 7 | 342924 | Ferrari Flangia Campana Trasmiss - 342924 | $1,664.45 | Special order, ships in 7-14 days |
| 8 | 14306624 | Ferrari Screw 8x35mm - 14306624 | $0.52 | Special order, ships in 7-14 days |
| 9 | 12602479 | Ferrari Washer D 8.3-1 - 12602479 | $0.27 | Available, ships in 3-6 days |
| 10 | 14059421 | Ferrari Flanged Nut 10x1.25 - 14059421 | $0.92 | Available, ships in 3-6 days |
| 11 | 102704 | Ferrari Dowel - 102704 | $6.10 | Available, ships in 3-6 days |
| 12 | 13543124 | Ferrari Stud Bolt M8x16 -Stem 16mm - 13543124 | $13.53 | Special order, ships in 7-14 days |
| 13 | 14306731 | Ferrari Screw TCEI M8 x 1.25 x 40 - 14306731 | $1.92 | Available, ships in 3-6 days |
| 14 | 14499401 | Ferrari Washer - 14499401 | $0.54 | Available, ships in 3-6 days |
| 14 | 14499424 | Ferrari Washer - 14499424 | Superseded | Order 14499401 instead |
| 15 | 341028 | Ferrari Travel Limiter Bracket Bush - 341028 | $189.56 | Special order, ships in 7-14 days |
| 16 | 18754324 | Ferrari Screw M10 x 1.25 x 32 - 18754324 | $3.03 | Available, ships in 3-6 days |
| 17 | 269664 | Ferrari Washer - 269664 | $8.49 | Available, ships in 3-6 days |
| 18 | 786862 | Ferrari Paratia Tampone Campana - 786862 | $118.16 | Special order, ships in 7-14 days |
| 19 | 11566724 | Ferrari Screw 5X25 - 11566724 | $3.91 | Available, ships in 3-6 days |
| 20 | 12638124 | Ferrari Washer - 12638124 | $0.08 | Available, ships in 3-6 days |
| 21 | 14059114 | Ferrari Nut M5 - 14059114 | $0.27 | Available, ships in 3-6 days |
| 22 | 329287 | Ferrari Tampone El.Campana Def. - 329287 | $467.80 | Special order, ships in 7-14 days |
| 23 | 255271 | Ferrari Nut M12 x 1.25 x - 255271 | $2.59 | Available, ships in 3-6 days |
| 24 | 854453 | Ferrari Bushing Travel Stop Bracket - 854453 | $212.92 | Special order, ships in 7-14 days |
| 25 | 13028734 | Ferrari Allen Screw M8 x 25 - 13028734 | $0.92 | Available, ships in 3-6 days |
