Ferrari Roma Spider — [MECHANICAL SYSTEM] - D.21 - SERVO BRAKE PIPES (diagram 0070)
Exploded view of the [mechanical system] - d.21 - servo brake pipes on the Ferrari Roma Spider, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [MECHANICAL SYSTEM] - D.21 - SERVO BRAKE PIPES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0070.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 893521 | Ferrari Brake Servo Vacuum Pipe - 893521 | $189.56 | Special order, ships in 7-14 days |
| 1 | 991206 | Ferrari Brake Servo Vacuum Pipe - 991206 | $270.83 | Special order, ships in 7-14 days |
| 1 | 923621 | Ferrari Tubaz.Depress.Servofreno S & - 923621 | Superseded | Order 991206 instead |
| 2 | 81840800 | Ferrari Clip - 81840800 | $0.79 | Special order, ships in 7-14 days |
| 3 | 250318 | Ferrari Clip - 250318 | $0.50 | Special order, ships in 7-14 days |
| 3 | 82396800 | Ferrari Clip - 82396800 | $2.01 | Special order, ships in 7-14 days |
