Ferrari Roma Spider — [MECHANICAL SYSTEM] - D.38 - TOOLS PROVIDED WITH VEHICLE (diagram 0093)
Exploded view of the [mechanical system] - d.38 - tools provided with vehicle on the Ferrari Roma Spider, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [MECHANICAL SYSTEM] - D.38 - TOOLS PROVIDED WITH VEHICLE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0093.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12643707 | Ferrari Washer - 12643707 | Superseded | Order 12643778 instead | |
| 12643777 | Ferrari Washer - 12643777 | Superseded | Order 12643778 instead | |
| 1 | 979903 | Ferrari Kit For Compl. Tool Kit - 979903 | $517.04 | Special order, ships in 7-14 days |
| 2 | 155838 | Ferrari Tow Hook - 155838 | $98.87 | In stock |
| 3 | 343204 | Ferrari P. Lock and RHT Release Tool - 343204 | $83.57 | Special order, ships in 7-14 days |
| 4 | 65253000 | Ferrari Accessory Holder Wallet Complete - 65253000 | $179.46 | Special order, ships in 7-14 days |
| 5 | 260763 | Ferrari Emergency Refuelling Funnel - 260763 | $61.99 | Available, ships in 3-6 days |
| 6 | 341813 | Ferrari DCT RELEASE PRECAUTIONS LABEL - 341813 | $34.40 | Special order, ships in 7-14 days |
| 7 | 83222200 | Ferrari Fastener Button - 83222200 | $1.42 | Available, ships in 3-6 days |
| 8 | 979714 | Ferrari Trousse Porta Attrezzi - 979714 | $241.27 | Special order, ships in 7-14 days |
| 9 | 976294 | Ferrari Puncture Repair Canister - 976294 | $516.33 | Special order, ships in 7-14 days |
| 10 | 12643778 | Ferrari Washer 6-18 x 1.5 - 12643778 | $0.54 | Available, ships in 3-6 days |
| 11 | 16285227 | Ferrari Screw M5 x 20 - 16285227 | $0.59 | Available, ships in 3-6 days |
