Ferrari Roma Spider — [VEHICLE TRIM] - E.2 - LATERAL OUTER BODYSHELL (diagram 0098)
Exploded view of the [vehicle trim] - e.2 - lateral outer bodyshell on the Ferrari Roma Spider, with 21 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [VEHICLE TRIM] - E.2 - LATERAL OUTER BODYSHELL exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0098.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 985882967 | Ferrari Front LH Fender - 985882967 | Superseded | Order 985951984 instead | |
| 985882963 | Ferrari Front RH Fender - 985882963 | Superseded | Order 985951991 instead | |
| 12643711 | Ferrari Washer - 12643711 | Superseded | Order 12643724 instead | |
| 12643721 | Ferrari Washer - 12643721 | Superseded | Order 12643724 instead | |
| 14499301 | Ferrari Washer - 14499301 | Superseded | Order 12643724 instead | |
| 1 | 985816923 | Ferrari RH Flank - 985816923 | $31,704.54 | Contact us to order |
| 2 | 985816878 | Ferrari LH Flank - 985816878 | $31,704.54 | Contact us to order |
| 3 | 985882961 | Ferrari Front RH Fender - 985882961 | $6,836.99 | Contact us to order |
| 3 | 985951991 | Ferrari Front RH Fender - 985951991 | $8,662.99 | Contact us to order |
| 4 | 985882973 | Ferrari Front LH Fender - 985882973 | $6,836.99 | Contact us to order |
| 4 | 985951984 | Ferrari Front LH Fender - 985951984 | $7,170.51 | Contact us to order |
| 5 | 985845136 | Ferrari Compl. RH Connector Bracket - 985845136 | $640.17 | Special order, ships in 7-14 days |
| 6 | 985845135 | Ferrari LH Connection Bracket - 985845135 | $640.17 | Special order, ships in 7-14 days |
| 7 | 985942380 | Ferrari Gutter Crosspiece - 985942380 | $3,250.16 | Special order, ships in 7-14 days |
| 8 | 82130200 | Ferrari Bracket - 82130200 | $13.01 | Special order, ships in 7-14 days |
| 9 | 16286121 | Ferrari Screw M6 x 20 - 16286121 | $1.23 | Available, ships in 3-6 days |
| 10 | 12643724 | Ferrari/Maserati Washer - 12643724 | $0.20 | In stock |
| 11 | 68040000 | Ferrari Washer 6X20x2 - 68040000 | $0.27 | Available, ships in 3-6 days |
| 12 | 12647724 | Ferrari Washer - 12647724 | $0.31 | Available, ships in 3-6 days |
| 13 | 10977621 | Ferrari Bolt - 10977621 | Superseded | Order 10977624 instead |
| 13 | 10977624 | Ferrari Screw TE M5 x 12 - 10977624 | $0.12 | Available, ships in 3-6 days |
