Ferrari Roma Spider — [VEHICLE TRIM] - E.3 - ROOF (diagram 0099)

Exploded view of the [vehicle trim] - e.3 - roof on the Ferrari Roma Spider, with 16 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Roma Spider [VEHICLE TRIM] - E.3 - ROOF exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14306521Ferrari Screw - 14306521SupersededOrder 14306524 instead
14306426Ferrari Seat Retaining Bolt - 14306426SupersededOrder 14306524 instead
13578311Ferrari Washer - 13578311SupersededOrder 13578324 instead
170008182Ferrari WINDSCREEN SURROUND TRIM - 70008182Price on requestContact us for price and availability
1985832718Ferrari Windscreen Surround Trim - 985832718$6,465.17Special order, ships in 7-14 days
214359324Ferrari Screw M8 x 65 TCEI - 14359324$1.61Available, ships in 3-6 days
312642021Ferrari Washer - 12642021$1.30Available, ships in 3-6 days
312642024Ferrari Washer - 12642024SupersededOrder 12642021 instead
4985833717Ferrari RH A-Pillar - 985833717$3,897.39Special order, ships in 7-14 days
5985833706Ferrari LH A-Pillar - 985833706$3,897.39Special order, ships in 7-14 days
6985855999Ferrari Upper Windscreen Cross Membe - 985855999$1,107.99Special order, ships in 7-14 days
783743800Ferrari Screw - 83743800$3.47Available, ships in 3-6 days
813578324Ferrari Washer 8.15-24x 2 - 13578324$0.44Available, ships in 3-6 days
914639591Ferrari Rivet - 14639591$3.03Available, ships in 3-6 days
1014306524Ferrari Screw M8 x 30mm - 14306524$0.65Available, ships in 3-6 days
1112625224Ferrari Washer - 12625224$0.13Available, ships in 3-6 days

All Roma Spider diagrams
