Ferrari Roma Spider — [VEHICLE TRIM] - E.16 - REAR SHIELDS (diagram 0115)
Exploded view of the [vehicle trim] - e.16 - rear shields on the Ferrari Roma Spider, with 5 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [VEHICLE TRIM] - E.16 - REAR SHIELDS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0115.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 980001 | Ferrari Compl. Gearbox Subframe Rear - 980001 | $1,009.51 | Special order, ships in 7-14 days |
| 2 | 778444 | Ferrari Rear Flat Undertray Foam - 778444 | $59.07 | Special order, ships in 7-14 days |
| 3 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 4 | 11626124 | Ferrari Screw 6x25 - 11626124 | Superseded | Order 11612826 instead |
| 4 | 11612826 | Ferrari Screw M6 x 25 - 11612826 | $6.75 | Available, ships in 3-6 days |
