Ferrari Roma Spider — [VEHICLE TRIM] - E.27 - SIDE WINDOWS (diagram 0126)
Exploded view of the [vehicle trim] - e.27 - side windows on the Ferrari Roma Spider, with 30 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [VEHICLE TRIM] - E.27 - SIDE WINDOWS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0126.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 995469 | Ferrari Flap Damper Foam - 995469 | Superseded | Order 807651 instead | |
| 81911200 | Ferrari Screw - 81911200 | Superseded | Order 85692200 instead | |
| 68176300 | Ferrari Screw 5x12 - 68176300 | Superseded | Order 85692200 instead | |
| 12638108 | Ferrari Washer - 12638108 | Superseded | Order 12638178 instead | |
| 12638177 | Ferrari Washer - 12638177 | Superseded | Order 12638178 instead | |
| 61276300 | Ferrari Washer - 61276300 | Superseded | Order 12638178 instead | |
| 1 | 851752 | Ferrari Compl. LH Quarterlight Windo - 851752 | $2,165.72 | Special order, ships in 7-14 days |
| 1 | 851766 | Ferrari Compl. RH Quarterlight Windo - 851766 | $2,165.72 | Special order, ships in 7-14 days |
| 2 | 851771 | Ferrari LH Rear Window Beltline Seal - 851771 | $1,116.19 | Special order, ships in 7-14 days |
| 2 | 851772 | Ferrari RH Rear Beltline Seal - 851772 | $1,116.19 | Special order, ships in 7-14 days |
| 3 | 974104 | Ferrari Lower Foam Seal For LH Rear - 974104 | $76.30 | Special order, ships in 7-14 days |
| 3 | 974105 | Ferrari Lower Foam Seal For RH Rear - 974105 | $76.30 | Special order, ships in 7-14 days |
| 4 | 974342 | Ferrari LH Fastener Bracket - 974342 | $41.82 | Special order, ships in 7-14 days |
| 4 | 974348 | Ferrari RH Fastener Bracket - 974348 | $41.82 | Special order, ships in 7-14 days |
| 5 | 85691900 | Ferrari Screw M5 x 8 TBFTX - 85691900 | $0.65 | Available, ships in 3-6 days |
| 6 | 85692200 | Ferrari SCREW M5 x 12 - 85692200 | $0.65 | Available, ships in 3-6 days |
| 7 | 15689801 | Ferrari Screw - 15689801 | $0.17 | Available, ships in 3-6 days |
| 8 | 12638178 | Ferrari Washer 5.45-14x1 - 12638178 | $0.13 | Available, ships in 3-6 days |
| 9 | 14115885 | Ferrari Fixing Block - 14115885 | $0.31 | Available, ships in 3-6 days |
| 10 | 851773 | Ferrari LH Quarterlight Window Lift - 851773 | $41.82 | Special order, ships in 7-14 days |
| 10 | 851775 | Ferrari RH Quarterlight Window Lift - 851775 | $41.82 | Special order, ships in 7-14 days |
| 11 | 16297024 | Ferrari Screw - 16297024 | $0.96 | Available, ships in 3-6 days |
| 12 | 10523178 | Ferrari Washer - 10523178 | $1.97 | Special order, ships in 7-14 days |
| 13 | 14040711 | Ferrari Nut M8 - 14040711 | $0.79 | Available, ships in 3-6 days |
| 14 | 87904300 | Ferrari Washer 8.15-36x2.5 - 87904300 | $3.03 | Special order, ships in 7-14 days |
| 15 | 63965800 | Ferrari Cap For Undertank Shield - 63965800 | $10.31 | Available, ships in 3-6 days |
| 16 | 831634 | Ferrari Adhesive Noise Insulation Se - 831634 | $6.98 | Special order, ships in 7-14 days |
| 17 | 807651 | Ferrari Guarnizione Adesiva Antirumo - 807651 | $7.86 | Special order, ships in 7-14 days |
| 18 | 921839 | Ferrari LH Gutter Water Drain Pipe - 921839 | $78.76 | Special order, ships in 7-14 days |
| 18 | 921840 | Ferrari RH Gutter Water Drain Pipe - 921840 | $78.76 | Special order, ships in 7-14 days |
