Ferrari Roma Spider — [VEHICLE TRIM] - E.47.07 - DASHBOARD - GLOVE COMPARTMENT (diagram 0155)
Exploded view of the [vehicle trim] - e.47.07 - dashboard - glove compartment on the Ferrari Roma Spider, with 34 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [VEHICLE TRIM] - E.47.07 - DASHBOARD - GLOVE COMPARTMENT exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0155.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 792590 | Ferrari Ball Joint - 792590 | Superseded | Order 88751300 instead | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 1 | 898045 | Ferrari Glove Compartment - 898045 | $320.06 | Special order, ships in 7-14 days |
| 1 | 914317 | Ferrari Glove Compartment - RHD - 914317 | $369.30 | Special order, ships in 7-14 days |
| 2 | 898040 | Ferrari Dashboard Glove Compartment - 898040 | $344.69 | Special order, ships in 7-14 days |
| 2 | 914308 | Ferrari Dashboard Glove Compartment - 914308 | $393.93 | Special order, ships in 7-14 days |
| 2 | 917453 | Ferrari Dashboard Glove Compartment - 917453 | $664.78 | Special order, ships in 7-14 days |
| 2 | 917584 | Ferrari Dashboard Glove Compartment - 917584 | $689.41 | Special order, ships in 7-14 days |
| 3 | 898039 | Ferrari Compl. Glove Compartment Lid - 898039 | Price on request | Contact us for price and availability |
| 3 | 914324 | Ferrari Compl. Glove Compartment Lid - 914324 | Price on request | Contact us for price and availability |
| 4 | 85691900 | Ferrari Screw M5 x 8 TBFTX - 85691900 | $0.65 | Available, ships in 3-6 days |
| 5 | 865568 | Ferrari Stabilus Gas Strut - 865568 | $85.22 | Special order, ships in 7-14 days |
| 6 | 88751300 | Ferrari Ball Joint - 88751300 | $49.14 | Special order, ships in 7-14 days |
| 7 | 89081300 | Ferrari Glove Compartment Hinge - 89081300 | $110.78 | Special order, ships in 7-14 days |
| 8 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 9 | 893768 | Ferrari Glove Compartment Lid Pivot - 893768 | $56.60 | Special order, ships in 7-14 days |
| 10 | 65361300 | Ferrari Pin - 65361300 | Superseded | Order 80810100 instead |
| 10 | 80810100 | Ferrari Rubber - 80810100 | $58.98 | Available, ships in 3-6 days |
| 11 | 89257000 | Ferrari Lock Striker - 89257000 | $56.52 | Special order, ships in 7-14 days |
| 12 | 85692000 | Ferrari SCREW - 85692000 | $0.65 | Available, ships in 3-6 days |
| 13 | 816023 | Ferrari SCREW - 816023 | $1.84 | Special order, ships in 7-14 days |
| 14 | 898031 | Ferrari Glove Compartment Lid - 898031 | $3,845.80 | Special order, ships in 7-14 days |
| 14 | 906381 | Ferrari Glove Compartment Lid - 906381 | $4,237.42 | Special order, ships in 7-14 days |
| 14 | 911267 | Ferrari GLOVE COMPARTMENT LID - 911267 | Price on request | Contact us for price and availability |
| 14 | 911456 | Ferrari Glove Compartment Lid - 911456 | $3,897.39 | Special order, ships in 7-14 days |
| 14 | 914304 | Ferrari Glove Compartment Lid - 914304 | $4,340.59 | Special order, ships in 7-14 days |
| 14 | 914381 | Ferrari Glove Compartment Lid - 914381 | Price on request | Contact us for price and availability |
| 16 | 936376 | Ferrari Card Reader Cover - 936376 | $162.48 | Special order, ships in 7-14 days |
| 16 | 936379 | Ferrari Card Reader Cover - 936379 | $150.17 | Special order, ships in 7-14 days |
| 17 | 873038 | Ferrari Secondary Tie Rod - 873038 | $9.81 | Special order, ships in 7-14 days |
| 18 | 806485 | Ferrari Glove Compartment Lid Actuat - 806485 | $26.24 | Special order, ships in 7-14 days |
| 19 | 863451 | Ferrari Primary Tie Rod - 863451 | $9.81 | Special order, ships in 7-14 days |
| 19 | 914359 | Ferrari Primary Tie Rod - 914359 | $11.54 | Special order, ships in 7-14 days |
| 21 | 11087776 | Ferrari Circlip - 11087776 | $0.13 | Available, ships in 3-6 days |
