Ferrari Roma Spider — [VEHICLE TRIM] - E.53 - OTHER INTERIOR TRIM ACCESSORIES (diagram 0165)
Exploded view of the [vehicle trim] - e.53 - other interior trim accessories on the Ferrari Roma Spider, with 18 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [VEHICLE TRIM] - E.53 - OTHER INTERIOR TRIM ACCESSORIES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0165.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 55043289 | Ferrari LH Front Seat Belt - 55043289 | Price on request | Contact us for price and availability |
| 1 | 55043313 | Ferrari LH FRONT SEAT BELT - 55043313 | Price on request | Contact us for price and availability |
| 1 | 55043319 | Ferrari RH FRONT SEAT BELT - 55043319 | Price on request | Contact us for price and availability |
| 1 | 55043321 | Ferrari RH Front Seat Belt - 55043321 | Price on request | Contact us for price and availability |
| 2 | 55043968 | Ferrari LH Rear Seat Belt - 55043968 | Price on request | Contact us for price and availability |
| 2 | 55043971 | Ferrari RH Rear Seat Belt - 55043971 | Price on request | Contact us for price and availability |
| 3 | 869964 | Ferrari Compl. LH Drive Gear Bracket - 869964 | $36.92 | Special order, ships in 7-14 days |
| 3 | 869967 | Ferrari Compl. RH Drive Gear Bracket - 869967 | $36.92 | Special order, ships in 7-14 days |
| 4 | 247856 | Ferrari Screw TORX M8 x 1.25x 25 - 247856 | $3.68 | Available, ships in 3-6 days |
| 5 | 963874 | Ferrari Screw M10x20 with washer - 963874 | $4.56 | Special order, ships in 7-14 days |
| 6 | 83717300 | Ferrari SCREW HEAD COVER - 83717300 | $10.25 | Special order, ships in 7-14 days |
| 7 | 83911900 | Ferrari Retractor Screw - 83911900 | $3.47 | Special order, ships in 7-14 days |
| 8 | 981830 | Ferrari Seat Belt Stop - 981830 | $1.40 | Special order, ships in 7-14 days |
| 9 | 903132 | Ferrari Rear Buckle Section - 903132 | $221.59 | Special order, ships in 7-14 days |
| 10 | 859586 | Ferrari Gentex Mirror - 859586 | $569.02 | Special order, ships in 7-14 days |
| 10 | 859658 | Ferrari Gentex Mirror - 859658 | $1,855.13 | Special order, ships in 7-14 days |
| 10 | 948334 | Ferrari Gentex Mirror - 948334 | $1,750.91 | Special order, ships in 7-14 days |
| 10 | 948336 | Ferrari Gentex Mirror - 948336 | $1,750.91 | Special order, ships in 7-14 days |
