Ferrari Roma Spider — [ELECTRICAL SYSTEM] - F.8 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM (diagram 0183)
Exploded view of the [electrical system] - f.8 - various fastenings for the electrical system on the Ferrari Roma Spider, with 48 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [ELECTRICAL SYSTEM] - F.8 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0183.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12486580 | Ferrari Botton - 12486580 | Superseded | Order 204781 instead | |
| 175871 | Ferrari Clip - 175871 | Superseded | Order 204781 instead | |
| 14569480 | Ferrari Clip 10x3.8 Black - 14569480 | $0.54 | Available, ships in 3-6 days | |
| 323365 | Ferrari Connector Fastener Clip - 323365 | Superseded | Order 204781 instead | |
| 14040514 | Ferrari Flanged Nut - 14040514 | Superseded | Order 13046011 instead | |
| 13046012 | Ferrari Nut - 13046012 | Superseded | Order 13046011 instead | |
| 291225 | Ferrari P clip Bracket With Sheath - 291225 | $7.86 | Special order, ships in 7-14 days | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 1 | 10442290 | Ferrari P Clip Bracket With Sheath - 10442290 | $1.42 | Special order, ships in 7-14 days |
| 2 | 175119 | Ferrari Bracket With Sheath - 175119 | $11.29 | Special order, ships in 7-14 days |
| 3 | 14059211 | Ferrari Flanged Nut - 14059211 | $0.13 | Available, ships in 3-6 days |
| 4 | 10418601 | Ferrari Clamp 14mm - 10418601 | $1.86 | Available, ships in 3-6 days |
| 5 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 6 | 231627 | Ferrari Screw M8 x 16 - 231627 | $1.25 | Available, ships in 3-6 days |
| 7 | 14059311 | Ferrari NUT - 14059311 | $0.52 | Available, ships in 3-6 days |
| 8 | 13046011 | Ferrari Flanged Nut - 13046011 | $0.73 | Available, ships in 3-6 days |
| 9 | 287686 | Ferrari Bracket With Sheath - 287686 | $90.95 | Special order, ships in 7-14 days |
| 10 | 68700800 | Ferrari CLIP - 68700800 | $1.92 | Available, ships in 3-6 days |
| 11 | 85833800 | Ferrari Screw M5 x 14 TBFTX - 85833800 | $0.90 | Available, ships in 3-6 days |
| 12 | 10448890 | Ferrari Bracket With Sheath - 10448890 | $4.16 | Available, ships in 3-6 days |
| 13 | 179309 | Ferrari ADHESIVE FOAM - 179309 | $8.28 | Available, ships in 3-6 days |
| 14 | 248061 | Ferrari Clip - 248061 | $4.12 | Available, ships in 3-6 days |
| 15 | 85159800 | Ferrari CONNECTOR - 85159800 | $34.40 | Special order, ships in 7-14 days |
| 16 | 84487000 | Ferrari CLIP - 84487000 | $6.96 | Special order, ships in 7-14 days |
| 17 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 18 | 88822200 | Ferrari Screw 4 x 10 - 88822200 | $1.30 | Special order, ships in 7-14 days |
| 19 | 179318 | Ferrari Aluminium Spacer For Rad Fan - 179318 | $4.56 | Special order, ships in 7-14 days |
| 20 | 16287127 | Ferrari Screw 8x20 - 16287127 | $0.92 | Special order, ships in 7-14 days |
| 21 | 14084111 | Ferrari Nut - 14084111 | Superseded | Order 11673111 instead |
| 22 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 23 | 920886 | Ferrari Retaining Clip - 920886 | $0.82 | Special order, ships in 7-14 days |
| 24 | 204781 | Ferrari Clip - 204781 | $1.67 | Available, ships in 3-6 days |
| 25 | 142798 | Ferrari Rubber Shim - 142798 | $2.82 | Available, ships in 3-6 days |
| 26 | 279762 | Ferrari Clamp - 279762 | $0.98 | Special order, ships in 7-14 days |
| 27 | 242384 | Ferrari Clip - 242384 | $0.59 | Available, ships in 3-6 days |
| 28 | 255869 | Ferrari Clip - 255869 | $3.91 | Special order, ships in 7-14 days |
| 29 | 145854 | Ferrari Cable tie 200mm - 145854 | $0.57 | Available, ships in 3-6 days |
| 30 | 244223 | Ferrari Clip - 244223 | $8.93 | Special order, ships in 7-14 days |
| 31 | 85692000 | Ferrari SCREW - 85692000 | $0.65 | Available, ships in 3-6 days |
| 32 | 338181 | Ferrari Retaining Clip - 338181 | $0.17 | Special order, ships in 7-14 days |
| 33 | 69708300 | Ferrari Clip - 69708300 | $2.59 | Available, ships in 3-6 days |
| 34 | 894196 | Ferrari Fastener Bracket - 894196 | $177.25 | Special order, ships in 7-14 days |
| 35 | 85692400 | Ferrari Screw M5 x 20 TBFTX - 85692400 | $0.92 | Available, ships in 3-6 days |
| 36 | 14059121 | Ferrari Nut M5 - 14059121 | $0.31 | Available, ships in 3-6 days |
| 37 | 15901401 | Ferrari Screw - 15901401 | $0.46 | Available, ships in 3-6 days |
| 38 | 14059214 | Ferrari Flanged Nut M6 - 14059214 | $0.38 | Available, ships in 3-6 days |
| 39 | 338182 | Ferrari Ring Clamp - 338182 | $0.17 | Special order, ships in 7-14 days |
| 40 | 898766 | Ferrari Ring Clamp - 898766 | $6.10 | Special order, ships in 7-14 days |
