Ferrari Roma Spider — [ELECTRICAL SYSTEM] - F.10 - AUDIO UNIT (diagram 0185)

Exploded view of the [electrical system] - f.10 - audio unit on the Ferrari Roma Spider, with 98 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Roma Spider [ELECTRICAL SYSTEM] - F.10 - AUDIO UNIT exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
951166Ferrari Dongle - 951166SupersededOrder 951168 instead
242694Ferrari GPS Antenna - 242694Price on requestContact us for price and availability
331961Ferrari GPS Antenna - 331961$154.46Special order, ships in 7-14 days
931307432Ferrari Navigation System Gps Antenna - 931307432SupersededOrder 789209 instead
14039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
10558628Ferrari Screw - 10558628SupersededOrder 66207700 instead
11566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
288974Ferrari USB Socket - 288974SupersededOrder 303226 instead
14303324Ferrari/Maserati Screw - 14303324$0.29In stock
1251541Ferrari Tweeter - 251541$56.79Special order, ships in 7-14 days
1321882Ferrari Tweeter - 321882$131.10Special order, ships in 7-14 days
215903801Ferrari Screw - 15903801SupersededOrder 15903870 instead
3328469Ferrari Woofer - 328469$1,289.48Special order, ships in 7-14 days
3334279Ferrari Woofer - 334279$183.56Special order, ships in 7-14 days
485834000Ferrari Screw M5 x 25 - 85834000$0.71Special order, ships in 7-14 days
5260130Ferrari LH Woofer Adapter - 260130$44.24Special order, ships in 7-14 days
5260131Ferrari RH Woofer Adapter - 260131$44.24Special order, ships in 7-14 days
670006011Ferrari Sd Card Navigation Maps - 70006011$1,256.70Special order, ships in 7-14 days
785833900Ferrari Screw M5 x 16 TBFTX - 85833900$0.65Available, ships in 3-6 days
885692300Ferrari Screw M5 x 20 TBFTX - 85692300$0.65Available, ships in 3-6 days
9253861Ferrari Twiddler - 253861$415.82Special order, ships in 7-14 days
1085833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
1155051845Ferrari Compl. Centre Display Cover - 55051845$11,169.27Special order, ships in 7-14 days
1155051847Ferrari Compl. Centre Display Cover - 55051847$13,629.20Special order, ships in 7-14 days
1155051848Ferrari Compl. Centre Display Cover - 55051848$14,391.32Special order, ships in 7-14 days
1155051849Ferrari Compl. Centre Display Cover - 55051849$11,169.27Special order, ships in 7-14 days
11961443Ferrari Compl. Centre Display Cover - 961443$10,765.93Special order, ships in 7-14 days
11961444Ferrari Compl. Centre Display Cover - 961444SupersededOrder 55051847 instead
11961445Ferrari Compl. Centre Display Cover - 961445SupersededOrder 55051848 instead
11961446Ferrari Compl. Centre Display Cover - 961446$11,392.05Special order, ships in 7-14 days
12866235Ferrari Ndp Display Passeggero Spec. - 866235$4,114.39Special order, ships in 7-14 days
1314039511Ferrari Nut - 14039511$0.54Available, ships in 3-6 days
14935814Ferrari Passive Start Antenna - 935814$126.73Special order, ships in 7-14 days
14925991Ferrari Passive Start Antenna RF Gen - 925991$126.73Available, ships in 3-6 days
15894195Ferrari Staffa Fissaggio Amplificato - 894195$152.62Special order, ships in 7-14 days
1611625824Ferrari Screw 6x18 - 11625824$0.71Available, ships in 3-6 days
1713046114Ferrari Flanged Nut - 13046114$0.31Available, ships in 3-6 days
18942475Ferrari Cavo Fibra Ottica Abit. F169 - 942475$689.41Special order, ships in 7-14 days
18773803Ferrari Passenger Compartment Fibre - 773803$590.91Special order, ships in 7-14 days
19914896Ferrari Dashboard Fibre Optic Cable - 914896$132.94Special order, ships in 7-14 days
2055065968Ferrari NIT - 55065968Price on requestContact us for price and availability
2055065969Ferrari NIT - 55065969Price on requestContact us for price and availability
2055065971Ferrari NIT - 55065971Price on requestContact us for price and availability
2055065972Ferrari NIT - 55065972$17,346.05Contact us to order
20886892Ferrari Nit - 886892$14,536.71Contact us to order
20886893Ferrari Nit - 886893$16,642.54Contact us to order
20886895Ferrari Nit - 886895$16,968.51Contact us to order
20886902Ferrari Nit - 886902$14,883.77Contact us to order
2188822200Ferrari Screw 4 x 10 - 88822200$1.30Special order, ships in 7-14 days
22783018Ferrari Dashboard DAB Antenna Cable - 783018$137.87Special order, ships in 7-14 days
22877188Ferrari Dashboard Wiring Loom DAB1 F169 Pt - 877188$108.31Special order, ships in 7-14 days
23921244Ferrari Dashboard Cable Dab2 - 921244$130.47Special order, ships in 7-14 days
23877187Ferrari Dashboard Wiring Loom DAB2 F169 Pt - 877187$120.62Special order, ships in 7-14 days
24756963Ferrari Fibre Optic Cable Mounting Bracket - 756963$19.42Special order, ships in 7-14 days
2513046014Ferrari Nut - 13046014$0.63Special order, ships in 7-14 days
26338181Ferrari Retaining Clip - 338181$0.17Special order, ships in 7-14 days
27338182Ferrari Ring Clamp - 338182$0.17Special order, ships in 7-14 days
28217854Ferrari CLAMP - 217854$0.52Available, ships in 3-6 days
29955518Ferrari Cavo Antenna Gps Abitacolo - 955518$1,009.51Special order, ships in 7-14 days
29955517Ferrari Cavo Antenna Gps/Dab2 - 955517$1,649.69Special order, ships in 7-14 days
30789209Ferrari GPS Antenna - 789209$155.15Special order, ships in 7-14 days
31771350Ferrari Fm2/Dab Amplifier - 771350$344.21Special order, ships in 7-14 days
32310778Ferrari Passive Start Antenna - 310778$26.20Available, ships in 3-6 days
3314059111Ferrari Flanged Nut M5 - 14059111$0.08Available, ships in 3-6 days
3465752800Ferrari Screw M4 x 10 TBEI - 65752800$4.12Available, ships in 3-6 days
35969204Ferrari Antenna Bt-Wifi Dual Band - 969204$96.14Special order, ships in 7-14 days
36324658Ferrari Midrange - 324658$306.38Special order, ships in 7-14 days
3785692000Ferrari SCREW - 85692000$0.65Available, ships in 3-6 days
38875005Ferrari USB Splitter - Apple Car Play Version - 875005$1,598.19Contact us to order
39940778Ferrari USB - Hub Splitter Bracket - 940778$78.76Special order, ships in 7-14 days
4014303224Ferrari Screw 4x16 - 14303224$1.15Special order, ships in 7-14 days
4116281827Ferrari Screw 5x14 - 16281827$0.46Special order, ships in 7-14 days
42877191Ferrari Cavo Usb Splitter-Presa Base - 877191$517.04Special order, ships in 7-14 days
43877192Ferrari Cavo Usb Splitter-Carplay - 877192$590.91Special order, ships in 7-14 days
44303226Ferrari USB Socket - 303226$100.78Special order, ships in 7-14 days
45848476Ferrari Presa Usb Smartphone Project - 848476$211.43Special order, ships in 7-14 days
47939096Ferrari 12 Channel Amplifier - 939096$8,123.11Special order, ships in 7-14 days
48331962Ferrari Am/Fm Amplifier - 331962$189.31Special order, ships in 7-14 days
48771349Ferrari Am/Fm Amplifier - 771349$240.94Special order, ships in 7-14 days
4966207700Ferrari Allen Head Screw 5x15 - 66207700$4.56Special order, ships in 7-14 days
50898228Ferrari Compl. Centre Display Cover - 898228$1,501.96Special order, ships in 7-14 days
50927905Ferrari Compl. Centre Display Cover - 927905$3,060.22Special order, ships in 7-14 days
50927949Ferrari Compl. Centre Display Cover - 927949$3,794.22Special order, ships in 7-14 days
53894192Ferrari Staffa Amplificatore Am Fm - 894192$46.75Special order, ships in 7-14 days
54894193Ferrari Fm2/Dab Amplifier Bracket - 894193$44.29Special order, ships in 7-14 days
55951168Ferrari MYFERRARI CONNECT ECU - 951168$1,920.19Special order, ships in 7-14 days
56928349Ferrari Compl. Drsc-Vics Kit - 928349$14,542.12Special order, ships in 7-14 days
57951766Ferrari 4-Way Usb Hub For Dsrc Jrc - 951766$1,598.19Special order, ships in 7-14 days
58960901Ferrari Dsrc/Hub Cable - 960901$140.32Special order, ships in 7-14 days
59958191Ferrari Dsrc 5.8Ghz Advance Antenna - 958191$181.93Special order, ships in 7-14 days
60960902Ferrari Dsrc Beacon Antenna Cable - 960902$83.68Special order, ships in 7-14 days
61326887Ferrari SDARS/GNSS COMBO ANTENNA - 326887Price on requestContact us for price and availability
62877176Ferrari Dashboard Sdars Cable - 877176$123.09Special order, ships in 7-14 days
6355004368Ferrari Passenger Compartment Sdars - 55004368$566.30Special order, ships in 7-14 days
64894198Ferrari Fm2 Amplifier - 894198$566.30Special order, ships in 7-14 days
64894197Ferrari Fm2/Dab Amplifier - 894197$590.91Special order, ships in 7-14 days
65955565Ferrari Am-Fm1 Cable - 955565$241.27Special order, ships in 7-14 days
6655013378Ferrari Nitto - 55013378$49.22Special order, ships in 7-14 days
