Ferrari Roma Spider — [ELECTRICAL SYSTEM] - F.11 - ANTI-THEFT SYSTEM (diagram 0186)
Exploded view of the [electrical system] - f.11 - anti-theft system on the Ferrari Roma Spider, with 39 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [ELECTRICAL SYSTEM] - F.11 - ANTI-THEFT SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0186.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days | |
| 81911200 | Ferrari Screw - 81911200 | Superseded | Order 85692200 instead | |
| 68176300 | Ferrari Screw 5x12 - 68176300 | Superseded | Order 85692200 instead | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 1 | 956025 | Ferrari E-Call TCU - 956025 | $3,526.61 | Special order, ships in 7-14 days |
| 1 | 824396 | Ferrari TCU Ecall / Svr - 824396 | $3,514.91 | Special order, ships in 7-14 days |
| 1 | 956023 | Ferrari Tcu Ecall Turchia - 956023 | $3,526.61 | Special order, ships in 7-14 days |
| 2 | 16285127 | Ferrari Screw M5 x 16 - 16285127 | $1.05 | Special order, ships in 7-14 days |
| 3 | 14059111 | Ferrari Flanged Nut M5 - 14059111 | $0.08 | Available, ships in 3-6 days |
| 3 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 4 | 895549 | Ferrari Key Screwdriver-Ring Kit - 895549 | $368.79 | Special order, ships in 7-14 days |
| 5 | 6326163 | Ferrari Secret Card Label For Keys - 6326163 | $4.39 | Special order, ships in 7-14 days |
| 6 | 336779 | Ferrari Compl. Anti-Theft System Siren - 336779 | $262.24 | Special order, ships in 7-14 days |
| 7 | 14040611 | Ferrari Nut M6 - 14040611 | $0.57 | Available, ships in 3-6 days |
| 8 | 293416 | Ferrari Master Dipole Anti-Lift Sensor - 293416 | $721.22 | Special order, ships in 7-14 days |
| 9 | 294011 | Ferrari Slave Dipole Sensor - 294011 | $437.71 | Special order, ships in 7-14 days |
| 10 | 85692200 | Ferrari SCREW M5 x 12 - 85692200 | $0.65 | Available, ships in 3-6 days |
| 11 | 55011038 | Ferrari Wrench - 55011038 | $2,682.68 | Special order, ships in 7-14 days |
| 11 | 55016574 | Ferrari Wrench - 55016574 | $2,682.68 | Special order, ships in 7-14 days |
| 11 | 55016575 | Ferrari WRENCH - 55016575 | Price on request | Contact us for price and availability |
| 11 | 55011037 | Ferrari Wrench - Keyless Go - 55011037 | $2,682.68 | Special order, ships in 7-14 days |
| 12 | 55080828 | Ferrari Key Fob - 55080828 | $565.49 | Available, ships in 3-6 days |
| 12 | 865295 | Ferrari Key Fob - 865295 | Superseded | Order 55080828 instead |
| 12 | 865703 | Ferrari Key Fob - 865703 | $1,475.26 | Special order, ships in 7-14 days |
| 12 | 923359 | Ferrari Key Fob - 923359 | $516.33 | Special order, ships in 7-14 days |
| 13 | 811665 | Ferrari Key And Block Kit - 811665 | $1,450.67 | Special order, ships in 7-14 days |
| 14 | 332825 | Ferrari Glonass Speaker - 332825 | $78.66 | Special order, ships in 7-14 days |
| 15 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 16 | 336506 | Ferrari Glonass Gps Antenna - 336506 | $102.69 | Special order, ships in 7-14 days |
| 17 | 336507 | Ferrari Glonass Gsm Antenna - 336507 | $102.69 | Special order, ships in 7-14 days |
| 18 | 179318 | Ferrari Aluminium Spacer For Rad Fan - 179318 | $4.56 | Special order, ships in 7-14 days |
| 19 | 865301 | Ferrari Screw - Torx M 1.4 x 5 - 865301 | $1.44 | Available, ships in 3-6 days |
| 21 | 983447 | Ferrari Microphone Grille - 983447 | $29.52 | Special order, ships in 7-14 days |
| 22 | 85692000 | Ferrari SCREW - 85692000 | $0.65 | Available, ships in 3-6 days |
| 23 | 865300 | Ferrari Key Ring - 865300 | $44.24 | Special order, ships in 7-14 days |
| 24 | 925517 | Ferrari Screwdriver Adapter - 925517 | $179.46 | Special order, ships in 7-14 days |
| 25 | 333337 | Ferrari Gsm Microphone - 333337 | $319.62 | Special order, ships in 7-14 days |
| 26 | 824398 | Ferrari RF Antenna For Svr - 824398 | $72.10 | Special order, ships in 7-14 days |
| 27 | 824397 | Ferrari Driver Card For Svr - 824397 | $491.74 | Special order, ships in 7-14 days |
