Ferrari Roma Spider — [ELECTRICAL SYSTEM] - F.16 - ADAS AND SENSORS (diagram 0191)
Exploded view of the [electrical system] - f.16 - adas and sensors on the Ferrari Roma Spider, with 16 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [ELECTRICAL SYSTEM] - F.16 - ADAS AND SENSORS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0191.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 55058987 | Ferrari Surround View Ecu - 55058987 | $7,283.59 | Special order, ships in 7-14 days |
| 1 | 949299 | Ferrari Surround View Ecu - 949299 | Superseded | Order 55058987 instead |
| 2 | 860355 | Ferrari Cavo Post Nsw F142M Fl - 860355 | $115.69 | Special order, ships in 7-14 days |
| 2 | 883185 | Ferrari Rcam Ext Cable F169 - 883185 | $123.09 | Special order, ships in 7-14 days |
| 3 | 909050 | Ferrari MPC CAMERA - 909050 | Price on request | Contact us for price and availability |
| 3 | 943289 | Ferrari Mpc Camera - 943289 | $2,345.00 | Special order, ships in 7-14 days |
| 4 | 294780 | Ferrari Allen Head Bolt with Washer M5X16 - 294780 | $0.98 | Special order, ships in 7-14 days |
| 5 | 55018598 | Ferrari MEDIUM RANGE RADAR - 55018598 | $2,204.29 | Special order, ships in 7-14 days |
| 5 | 950074 | Ferrari Medium Range Radar - 950074 | $2,204.29 | Special order, ships in 7-14 days |
| 6 | 764923 | Ferrari Front Crash Sensor - 764923 | $74.29 | Available, ships in 3-6 days |
| 7 | 231620 | Ferrari/Maserati Screw - 231620 | $0.58 | In stock |
| 8 | 263079 | Ferrari Accelerator For Magneride System - 263079 | Superseded | Order 990305 instead |
| 8 | 990305 | Ferrari Accelerator For Magneride System - 990305 | $442.56 | Available, ships in 3-6 days |
| 9 | 764924 | Ferrari LATERAL CRASH SENSOR - 764924 | $74.29 | Special order, ships in 7-14 days |
| 10 | 786808 | Ferrari Rain And Twilight Sensor - 786808 | $393.38 | Special order, ships in 7-14 days |
| 11 | 826105 | Ferrari Front Camera Cable - 826105 | $132.94 | Special order, ships in 7-14 days |
