Ferrari Roma — [ENGINE] - B.15 - INJECTION CONTROL (diagram 0020)
Exploded view of the [engine] - b.15 - injection control on the Ferrari Roma, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma [ENGINE] - B.15 - INJECTION CONTROL exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma/0020.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 279575 | Ferrari Throttle Body - 279575 | Superseded | Order 329966 instead | |
| 1 | 329966 | Ferrari Throttle Body - 329966 | $615.54 | Special order, ships in 7-14 days |
| 2 | 255494 | Ferrari Screw - 255494 | $18.76 | Available, ships in 3-6 days |
| 3 | 309966 | Ferrari Air Pressure Sensor - 309966 | $151.00 | Special order, ships in 7-14 days |
| 4 | 329640 | Ferrari Air Pressure Sensor Pipe - 329640 | $103.38 | Special order, ships in 7-14 days |
| 5 | 340221 | Ferrari Screw - 340221 | $1.59 | Special order, ships in 7-14 days |
| 6 | 13125170 | Ferrari Clamp - 13125170 | $1.48 | Special order, ships in 7-14 days |
