Ferrari Roma — [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK (diagram 0064)
Exploded view of the [mechanical system] - d.15 - expansion tank on the Ferrari Roma, with 39 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma/0064.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 262112 | Ferrari Collar - 262112 | Superseded | Order 262111 instead | |
| 296675 | Ferrari Compl. Header Tank Breather - 296675 | Superseded | Order 787062 instead | |
| 787061 | Ferrari Compl. Header Tank Breather - 787061 | Superseded | Order 787062 instead | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 216568 | Ferrari Screw 6x30 - 216568 | Superseded | Order 231621 instead | |
| 10860270 | Ferrari Screw Collar - 10860270 | $1.94 | Available, ships in 3-6 days | |
| 10860370 | Ferrari Screw Collar - 10860370 | $3.26 | Special order, ships in 7-14 days | |
| 13127770 | Ferrari Screw Collar - 13127770 | $2.82 | Special order, ships in 7-14 days | |
| 268210 | Ferrari Screw Collar - 268210 | $6.32 | Special order, ships in 7-14 days | |
| 14498804 | Ferrari Washer - 14498804 | Superseded | Order 14498824 instead | |
| 1 | 882791 | Ferrari Serb.Espansione Cpl - 882791 | $295.43 | Special order, ships in 7-14 days |
| 2 | 145030 | Ferrari Radiator Cap - 145030 | $89.98 | In stock |
| 3 | 305321 | Ferrari Rubber Pipe - 305321 | $110.78 | Special order, ships in 7-14 days |
| 4 | 262559 | Ferrari Clip - 262559 | $1.78 | Available, ships in 3-6 days |
| 5 | 10397380 | Ferrari Ring - 10397380 | $2.82 | Available, ships in 3-6 days |
| 6 | 286491 | Ferrari Spacer - 286491 | $66.35 | Special order, ships in 7-14 days |
| 7 | 286492 | Ferrari Cable Grommet - 286492 | $66.35 | Special order, ships in 7-14 days |
| 8 | 12640624 | Ferrari Plain Washer 6mm - 12640624 | $0.31 | Available, ships in 3-6 days |
| 9 | 231621 | Ferrari Allen Screw M6 x 30 TCEI - 231621 | $0.73 | Available, ships in 3-6 days |
| 10 | 262111 | Ferrari Screw Collar - 262111 | $3.03 | Special order, ships in 7-14 days |
| 11 | 781442 | Ferrari Tubo Carico Nuorice - 781442 | $100.93 | Special order, ships in 7-14 days |
| 12 | 330681 | Ferrari Tubo Caricam.Imp. Raffr.La - 330681 | $73.85 | Special order, ships in 7-14 days |
| 13 | 262109 | Ferrari Screw Collar - 262109 | $2.01 | Available, ships in 3-6 days |
| 14 | 296672 | Ferrari Rubber Pipe - 296672 | $27.06 | Special order, ships in 7-14 days |
| 15 | 288386 | Ferrari Rubber Pipe 7-14X107 - 288386 | $29.48 | Available, ships in 3-6 days |
| 16 | 787062 | Ferrari Compl. Header Tank Breather - 787062 | $369.30 | Special order, ships in 7-14 days |
| 17 | 782311 | Ferrari Tubo Gomma D.7X14 D5.5X12. - 782311 | $41.82 | Special order, ships in 7-14 days |
| 18 | 306692 | Ferrari Clip Set - 306692 | $1.11 | Special order, ships in 7-14 days |
| 19 | 198259 | Ferrari Clip - 198259 | $13.74 | Special order, ships in 7-14 days |
| 20 | 140727 | Ferrari Clip - 140727 | $0.48 | In stock |
| 21 | 140130 | Ferrari Clip - 140130 | $0.27 | Available, ships in 3-6 days |
| 22 | 13125470 | Ferrari Collar - 13125470 | Superseded | Order 13126970 instead |
| 23 | 336090 | Ferrari Header Tank Mounting Bracket - 336090 | $34.44 | Special order, ships in 7-14 days |
| 24 | 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days |
| 24 | 15896214 | Ferrari Nut M6 x 5 - 15896214 | Superseded | Order 14039614 instead |
| 25 | 225408 | Ferrari Cylindrical Bushing - 225408 | $12.99 | Special order, ships in 7-14 days |
| 26 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 27 | 62766300 | Ferrari Spire Clip M6 - 62766300 | $1.36 | Available, ships in 3-6 days |
| 28 | 290935 | Ferrari Radiator Mounting Bush - 290935 | $12.67 | Available, ships in 3-6 days |
