Ferrari Roma — [VEHICLE TRIM] - E.01.03 - STRUCTURES AND ELEMENTS REAR OF VEHICLE (diagram 0097)

Exploded view of the [vehicle trim] - e.01.03 - structures and elements rear of vehicle on the Ferrari Roma, with 49 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Roma [VEHICLE TRIM] - E.01.03 - STRUCTURES AND ELEMENTS REAR OF VEHICLE exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
985335301Ferrari Complete Spare Wheel Tray - 985335301SupersededOrder 985927818 instead
985337554Ferrari LH Strut - 985337554$2,074.75Special order, ships in 7-14 days
985337555Ferrari RH Strut - 985337555$2,074.75Special order, ships in 7-14 days
128944Ferrari Washer D10.2-20 - 128944$3.68Available, ships in 3-6 days
1985938113Ferrari Gearbox Subchassis - 985938113$54,959.90Contact us to order
2985835413Ferrari Compl. RH Upper Rear Suspens - 985835413$7,614.24Special order, ships in 7-14 days
3985835412Ferrari Compl. LH Upper Rear Suspens - 985835412$7,572.02Special order, ships in 7-14 days
4985867434Ferrari Compl. Centre Rear Bench Rei - 985867434$1,280.35Special order, ships in 7-14 days
5985938455Ferrari Compl. LH Rear Bench - 985938455$3,766.07Special order, ships in 7-14 days
5985938457Ferrari Compl. RH Rear Bench - 985938457$3,789.52Special order, ships in 7-14 days
6985339745Ferrari LH Inner Flank - 985339745$1,107.99Special order, ships in 7-14 days
6985339746Ferrari RH Inner Flank - 985339746$1,107.99Special order, ships in 7-14 days
7985339727Ferrari Compl. LH Outer Flank - 985339727$837.14Special order, ships in 7-14 days
7985868682Ferrari Compl. LH Outer Flank - 985868682$1,083.38Special order, ships in 7-14 days
7985339729Ferrari Compl. RH Outer Flank - 985339729$837.14Special order, ships in 7-14 days
7985868685Ferrari Compl. RH Outer Flank - 985868685$1,083.38Special order, ships in 7-14 days
8985860980Ferrari Compl. LH Upper Rear Diagona - 985860980SupersededOrder 985910521 instead
8985910521Ferrari Compl. LH Upper Rear Diagona - 985910521$1,181.86Special order, ships in 7-14 days
8985860982Ferrari Compl. RH Upper Rear Diagona - 985860982SupersededOrder 985910524 instead
8985910524Ferrari Compl. RH Upper Rear Diagona - 985910524$1,255.72Special order, ships in 7-14 days
9985339878Ferrari Lower LH Rear Diagonal Brace - 985339878$1,157.24Special order, ships in 7-14 days
9985860491Ferrari Lower LH Rear Diagonal Brace - 985860491$911.01Special order, ships in 7-14 days
9985339879Ferrari Lower RH Rear Diagonal Brace - 985339879$1,157.24Special order, ships in 7-14 days
9985952848Ferrari Lower RH Rear Diagonal Brace - 985952848$911.01Special order, ships in 7-14 days
10985852073Ferrari Compl. Rear Tank End Cross M - 985852073$4,099.06Special order, ships in 7-14 days
11985337557Ferrari RH K-Brace - 985337557$1,008.09Special order, ships in 7-14 days
12985337556Ferrari LH K-Brace - 985337556$1,008.09Special order, ships in 7-14 days
13985832490Ferrari Rear RH Strut - 985832490$2,157.38Special order, ships in 7-14 days
13985861872Ferrari Rear RH Strut - 985861872$1,696.56Special order, ships in 7-14 days
13985771957Ferrari RH Strut - 985771957$4,007.60Special order, ships in 7-14 days
14985771956Ferrari LH Strut - 985771956$4,007.60Special order, ships in 7-14 days
14985832489Ferrari Rear LH Strut - 985832489$2,204.29Special order, ships in 7-14 days
14985861869Ferrari Rear LH Strut - 985861869SupersededOrder 985832489 instead
14985978759Ferrari Rear LH Strut - 985978759SupersededOrder 985832489 instead
15985832484Ferrari Complete Spare Wheel Tray - 985832484$3,076.63Special order, ships in 7-14 days
15985927818Ferrari Complete Spare Wheel Tray - 985927818$2,722.54Special order, ships in 7-14 days
1616289834Ferrari Screw Flanged M12 x 1.25 x 30 - 16289834$2.82Available, ships in 3-6 days
17252486Ferrari Threaded Insert - 252486$66.35Special order, ships in 7-14 days
18749854Ferrari Screw TE M12 x 1.25 x 75 with Washer - 749854$8.95Available, ships in 3-6 days
19749853Ferrari Screw TE M10 x 1.25 x 60 with Washer - 749853$5.44Available, ships in 3-6 days
20252200Ferrari Threaded Insert - 252200$18.32Special order, ships in 7-14 days
2168984500Ferrari Screw TEF M10 x 1.25 x 30 - 68984500$5.86Available, ships in 3-6 days
22985334254Ferrari Rear LH Hose Bracket - 985334254$517.04Special order, ships in 7-14 days
22985334256Ferrari Rear RH Hose Bracket - 985334256$517.04Special order, ships in 7-14 days
23299578Ferrari Hex Head Screw M10X1.25X70 Con 2 Ro - 299578$5.65Special order, ships in 7-14 days
2411306934Ferrari Screw M10 x 1.25 x 30 - 11306934$1.04Available, ships in 3-6 days
2513550424Ferrari Washer - 13550424$0.31Available, ships in 3-6 days
2513550401Ferrari Washer 10.2-20x2 - 13550401$0.31Available, ships in 3-6 days
2685492800Ferrari Acoustic Closure Cap 28 x 22 - 85492800$3.41Special order, ships in 7-14 days

All Roma diagrams
