Ferrari Roma — [VEHICLE TRIM] - E.18 - REAR WHEELHOUSE (diagram 0117)
Exploded view of the [vehicle trim] - e.18 - rear wheelhouse on the Ferrari Roma, with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma [VEHICLE TRIM] - E.18 - REAR WHEELHOUSE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma/0117.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 968268 | Ferrari LH Rear Wheelhouse - 968268 | $437.71 | Special order, ships in 7-14 days |
| 1 | 978044 | Ferrari LH Rear Wheelhouse - 978044 | $437.71 | Special order, ships in 7-14 days |
| 1 | 968265 | Ferrari RH Rear Wheelhouse - 968265 | $437.71 | Special order, ships in 7-14 days |
| 1 | 978741 | Ferrari RH Rear Wheelhouse - 978741 | $437.71 | Special order, ships in 7-14 days |
| 2 | 14189071 | Ferrari M6 x 1Screw clip - 14189071 | $1.36 | Available, ships in 3-6 days |
| 3 | 80874100 | Ferrari Screw Torx - 80874100 | $1.97 | Available, ships in 3-6 days |
| 3 | 82113500 | Ferrari Screw Torx M6 x 18 with Washer D. 15 - 82113500 | $5.86 | Available, ships in 3-6 days |
| 4 | 83222200 | Ferrari Fastener Button - 83222200 | $1.42 | Available, ships in 3-6 days |
| 5 | 82362500 | Ferrari Screw - 82362500 | $1.49 | Available, ships in 3-6 days |
| 6 | 84247300 | Ferrari Male Clip - 84247300 | $2.82 | Available, ships in 3-6 days |
| 7 | 84247400 | Ferrari Female Clip - 84247400 | $2.59 | Available, ships in 3-6 days |
