Ferrari Roma — [VEHICLE TRIM] - E.29.02 - DOORS - OPENING MECHANISMS AND HINGES (diagram 0129)
Exploded view of the [vehicle trim] - e.29.02 - doors - opening mechanisms and hinges on the Ferrari Roma, with 48 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma [VEHICLE TRIM] - E.29.02 - DOORS - OPENING MECHANISMS AND HINGES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma/0129.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 15896214 | Ferrari Nut M6 x 5 - 15896214 | Superseded | Order 14039614 instead | |
| 1 | 901337 | Ferrari LH Front Door Membrane - 901337 | $91.08 | Special order, ships in 7-14 days |
| 1 | 901338 | Ferrari RH Front Door Membrane - 901338 | $91.08 | Available, ships in 3-6 days |
| 2 | 967654 | Ferrari LH Door Waterproof Membrane - 967654 | $59.07 | Special order, ships in 7-14 days |
| 2 | 967655 | Ferrari RH Door Waterproof Membrane - 967655 | $59.07 | Special order, ships in 7-14 days |
| 3 | 880232 | Ferrari Upper Cover - 880232 | $12.99 | Special order, ships in 7-14 days |
| 4 | 831375 | Ferrari Compl. Door Handle - 831375 | $19.40 | Special order, ships in 7-14 days |
| 4 | 880201 | Ferrari Maniglia Back-Up Apertura Po - 880201 | Superseded | Order 831375 instead |
| 5 | 952875 | Ferrari Bowden Maniglia Interna Port - 952875 | $91.08 | Special order, ships in 7-14 days |
| 6 | 806665 | Ferrari LH Door Lock - 806665 | $984.88 | Special order, ships in 7-14 days |
| 6 | 879595 | Ferrari LH Door Lock - 879595 | $984.88 | Special order, ships in 7-14 days |
| 6 | 806668 | Ferrari RH Door Lock - 806668 | $984.88 | Special order, ships in 7-14 days |
| 6 | 879597 | Ferrari RH Door Lock - 879597 | $984.88 | Special order, ships in 7-14 days |
| 7 | 80874100 | Ferrari Screw Torx - 80874100 | $1.97 | Available, ships in 3-6 days |
| 8 | 85133400 | Ferrari Screw TSEI M8 x 20 - 85133400 | $1.30 | Available, ships in 3-6 days |
| 9 | 808736 | Ferrari Door Lock Striker Plate - 808736 | $29.48 | Special order, ships in 7-14 days |
| 10 | 924578 | Ferrari Pellicola Per Scontrino Port - 924578 | $14.39 | Special order, ships in 7-14 days |
| 11 | 802693 | Ferrari Door Striker Plate Shim - 802693 | $15.05 | Special order, ships in 7-14 days |
| 11 | 848279 | Ferrari Door Striker Plate Shim - 848279 | Superseded | Order 802693 instead |
| 12 | 787474 | Ferrari LH Outer Door Handle Module - 787474 | $443.17 | Special order, ships in 7-14 days |
| 12 | 805772 | Ferrari LH Outer Door Handle Module - 805772 | Superseded | Order 787474 instead |
| 12 | 787460 | Ferrari Modulo Maniglia Est Cpl - 787460 | $714.03 | Special order, ships in 7-14 days |
| 12 | 787467 | Ferrari RH Outer Door Handle Module - 787467 | $443.17 | Special order, ships in 7-14 days |
| 12 | 787476 | Ferrari RH Outer Door Handle Module - 787476 | $714.03 | Special order, ships in 7-14 days |
| 12 | 805799 | Ferrari RH Outer Door Handle Module - 805799 | Superseded | Order 787476 instead |
| 13 | 13046114 | Ferrari Flanged Nut - 13046114 | $0.31 | Available, ships in 3-6 days |
| 13 | 13832101 | Ferrari Flanged Nut M6 - 13832101 | $0.27 | Available, ships in 3-6 days |
| 13 | 13046111 | Ferrari Nut 6x6 - 13046111 | $0.73 | Special order, ships in 7-14 days |
| 14 | 970486 | Ferrari LH Handle Two/Component Paddle - 970486 | $98.46 | Special order, ships in 7-14 days |
| 14 | 970491 | Ferrari RH Handle Two/Component Paddle - 970491 | $98.46 | Special order, ships in 7-14 days |
| 15 | 939899 | Ferrari LH Handle Button - 939899 | $22.87 | Special order, ships in 7-14 days |
| 15 | 940534 | Ferrari RH Handle Button - 940534 | $22.87 | Special order, ships in 7-14 days |
| 16 | 69877300 | Ferrari Door Arrester Tie-Rod - 69877300 | $108.31 | Special order, ships in 7-14 days |
| 16 | 952826 | Ferrari Tirante Arresto Porta Contin - 952826 | Superseded | Order 69877300 instead |
| 17 | 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days |
| 18 | 84872900 | Ferrari Screw - 84872900 | $0.82 | Available, ships in 3-6 days |
| 19 | 83897000 | Ferrari Door Arrester Tie-Rod Seal - 83897000 | $24.32 | Special order, ships in 7-14 days |
| 20 | 14059311 | Ferrari NUT - 14059311 | $0.52 | Available, ships in 3-6 days |
| 21 | 815687 | Ferrari Tappo Otturazione Asola - 815687 | $13.32 | Special order, ships in 7-14 days |
| 22 | 12578011 | Ferrari Flanged Nyloc Nut - 12578011 | $0.31 | Available, ships in 3-6 days |
| 23 | 263032 | Ferrari Camber Spacer 0.5mm - 263032 | $24.02 | Available, ships in 3-6 days |
| 23 | 263033 | Ferrari Camber Spacer 1.0mm - 263033 | $7.19 | Special order, ships in 7-14 days |
| 23 | 263034 | Ferrari Camber Spacer 1.5mm - 263034 | $7.19 | Special order, ships in 7-14 days |
| 23 | 263035 | Ferrari Camber Spacer 2.0mm - 263035 | $7.19 | Available, ships in 3-6 days |
| 24 | 238692 | Ferrari Camber Spacer 0.5mm - 238692 | $12.65 | Special order, ships in 7-14 days |
| 24 | 238693 | Ferrari Camber Spacer 1.0mm - 238693 | $10.25 | Special order, ships in 7-14 days |
| 24 | 238881 | Ferrari Camber Spacer 1.5mm - 238881 | $10.25 | Special order, ships in 7-14 days |
| 24 | 238694 | Ferrari Camber Spacer 2.0mm - 238694 | Superseded | Order 263035 instead |
