Ferrari Roma — [VEHICLE TRIM] - E.42 - REAR ACTIVE AERO (diagram 0144)
Exploded view of the [vehicle trim] - e.42 - rear active aero on the Ferrari Roma, with 15 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma [VEHICLE TRIM] - E.42 - REAR ACTIVE AERO exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma/0144.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 70007118 | Ferrari Compl. Rear Variable Geom. W - 70007118 | $20,687.35 | Contact us to order |
| 1 | 783009 | Ferrari Compl. Rear Variable Geom. W - 783009 | Superseded | Order 804585 instead |
| 1 | 784511 | Ferrari Compl. Rear Variable Geom. W - 784511 | Superseded | Order 804588 instead |
| 1 | 804585 | Ferrari Compl. Rear Variable Geom. W - 804585 | $3,046.15 | Special order, ships in 7-14 days |
| 1 | 804588 | Ferrari Compl. Rear Variable Geom. W - 804588 | $3,662.88 | Special order, ships in 7-14 days |
| 2 | 779360 | Ferrari Compl. Variable Geometry Wing Tray - 779360 | $6,326.83 | Special order, ships in 7-14 days |
| 3 | 774707 | Ferrari Torx Screw M6X18 Ros.Imp. D.1 - 774707 | $5.65 | Special order, ships in 7-14 days |
| 4 | 983365 | Ferrari Washer D.6.2x20x1.5 - 983365 | $0.63 | Special order, ships in 7-14 days |
| 5 | 775076 | Ferrari Screw M6 x 35 - 775076 | $8.72 | Special order, ships in 7-14 days |
| 6 | 70007126 | Ferrari Ferrari Badge - 70007126 | $86.15 | Special order, ships in 7-14 days |
| 6 | 968767 | Ferrari Ferrari Script - 3 Pin - 968767 | $162.48 | Special order, ships in 7-14 days |
| 7 | 84952000 | Ferrari Cosmetic Cap - 84952000 | $16.45 | Available, ships in 3-6 days |
| 8 | 963941 | Ferrari Tubo Scolo Acqua Vasca Ala M - 963941 | $78.76 | Special order, ships in 7-14 days |
| 9 | 161490 | Ferrari Hose Clip 12 - 20 x 9 - 161490 | $3.91 | Available, ships in 3-6 days |
| 10 | 927664 | Ferrari Clip Connector - Rotatable - 927664 | $4.14 | Special order, ships in 7-14 days |
