Ferrari Roma — [VEHICLE TRIM] - E.55 - WIPERS AND HEADLAMP WASHERS (diagram 0167)
Exploded view of the [vehicle trim] - e.55 - wipers and headlamp washers on the Ferrari Roma, with 42 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma [VEHICLE TRIM] - E.55 - WIPERS AND HEADLAMP WASHERS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma/0167.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 82199100 | Ferrari Screen Wash Liquid Reservoir - 82199100 | Superseded | Order 851829 instead | |
| 106853 | Ferrari Spring Washer 10mm - 106853 | Superseded | Order 12601474 instead | |
| 10516873 | Ferrari Washer - 10516873 | Superseded | Order 12601474 instead | |
| 12601471 | Ferrari Washer - 12601471 | Superseded | Order 12601474 instead | |
| 12640606 | Ferrari Washer - 12640606 | Superseded | Order 12640678 instead | |
| 12640608 | Ferrari Washer - 12640608 | Superseded | Order 12640678 instead | |
| 12640677 | Ferrari Washer - 12640677 | Superseded | Order 12640678 instead | |
| 1 | 936825 | Ferrari Compl. Screen Wash Reservoir - 936825 | $738.64 | Special order, ships in 7-14 days |
| 1 | 883481 | Ferrari Serbatoio Tergi Cpl - 883481 | $615.54 | Special order, ships in 7-14 days |
| 2 | 82198600 | Ferrari Filler Pipe Seal - 82198600 | $44.24 | Special order, ships in 7-14 days |
| 3 | 883479 | Ferrari Compl. Screen Wash Reservoir - 883479 | $233.89 | Special order, ships in 7-14 days |
| 4 | 851829 | Ferrari Screen Wash Liquid Reservoir - 851829 | $66.35 | Special order, ships in 7-14 days |
| 4 | 977650 | Ferrari Screen Wash Liquid Reservoir - 977650 | Superseded | Order 851829 instead |
| 5 | 787798 | Ferrari Driver Side Windscreen Wiper - 787798 | $13.01 | Special order, ships in 7-14 days |
| 5 | 787805 | Ferrari Drivers Side Windscreen Wiper Blade Lower Cover - 787805 | $10.31 | Special order, ships in 7-14 days |
| 6 | 81633200 | Ferrari Gasket - 81633200 | $50.24 | Special order, ships in 7-14 days |
| 7 | 81633100 | Ferrari Fluid Level Sensor - 81633100 | $240.39 | Special order, ships in 7-14 days |
| 8 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 9 | 81632900 | Ferrari Windscreen Washer Pump - 81632900 | $172.84 | Available, ships in 3-6 days |
| 10 | 65511700 | Ferrari Seal For Washer Pump - 65511700 | $9.81 | Available, ships in 3-6 days |
| 11 | 890994 | Ferrari Windscreen Washer Pipe - 890994 | $66.45 | Special order, ships in 7-14 days |
| 12 | 82984600 | Ferrari Check Valve (3 Way) - 82984600 | Price on request | Contact us for price and availability |
| 13 | 812606 | Ferrari Gruppo Tergicristallo Parabr - 812606 | $1,477.33 | Special order, ships in 7-14 days |
| 13 | 860816 | Ferrari Gruppo Tergicristallo Parabr - 860816 | Superseded | Order 812606 instead |
| 13 | 812610 | Ferrari Windscreen Wiper Assembly - 812610 | $1,477.33 | Special order, ships in 7-14 days |
| 14 | 959223 | Ferrari Braccio Tergicrist.Lato Guid - 959223 | $689.41 | Special order, ships in 7-14 days |
| 14 | 959225 | Ferrari Compl. Driver Side Windscree - 959225 | $689.41 | Special order, ships in 7-14 days |
| 15 | 15811787 | Ferrari Protective Cap 17 x 10.5 - 15811787 | $1.53 | Available, ships in 3-6 days |
| 16 | 10791021 | Ferrari Nut LHD - 10791021 | $1.25 | Available, ships in 3-6 days |
| 17 | 959220 | Ferrari Compl. Passenger Side Windsc - 959220 | $689.41 | Special order, ships in 7-14 days |
| 17 | 959226 | Ferrari Compl. Passenger Side Windsc - 959226 | $689.41 | Special order, ships in 7-14 days |
| 18 | 881925 | Ferrari Driver Side Windscreen Wiper - 881925 | $181.64 | Available, ships in 3-6 days |
| 18 | 917134 | Ferrari Driver Side Windscreen Wiper Blade - 917134 | $183.83 | Available, ships in 3-6 days |
| 19 | 881927 | Ferrari Passenger Side Windscreen Wiper - 881927 | $133.48 | Available, ships in 3-6 days |
| 19 | 917125 | Ferrari Passenger Side Windscreen Wiper Blade - 917125 | $133.48 | Available, ships in 3-6 days |
| 20 | 10903034 | Ferrari Screw 6x35 - 10903034 | $0.82 | Available, ships in 3-6 days |
| 21 | 12640678 | Ferrari Washer 6.15x25x2 - 12640678 | $3.47 | Available, ships in 3-6 days |
| 22 | 764005 | Ferrari Driver Side Windscreen Wiper - 764005 | $24.34 | Special order, ships in 7-14 days |
| 22 | 787529 | Ferrari Driver Side Windscreen Wiper - 787529 | $86.15 | Special order, ships in 7-14 days |
| 22 | 750004 | Ferrari Drivers Side Wiper Blade Upper Cover - 750004 | $20.41 | Special order, ships in 7-14 days |
| 22 | 779339 | Ferrari Drivers Side Wiper Blade Upper Cover - 779339 | Superseded | Order 750004 instead |
| 23 | 12601474 | Ferrari Wavy Washer 10mm - 12601474 | $0.06 | Available, ships in 3-6 days |
