Ferrari Roma — [ELECTRICAL SYSTEM] - F.1 - BATTERIES (diagram 0176)
Exploded view of the [electrical system] - f.1 - batteries on the Ferrari Roma, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma [ELECTRICAL SYSTEM] - F.1 - BATTERIES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma/0176.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 214466 | Ferrari Battery 70AH - L3 VRLA 760A - 214466 | Superseded | Order 312188 instead | |
| 168852 | Ferrari Battery 70AH 12 V Type VR 760 - 168852 | Superseded | Order 312188 instead | |
| 341745 | Ferrari Tubo Sfiato Batteriaf164 Vas - 341745 | Superseded | Order 815156 instead | |
| 1 | 312188 | Ferrari Battery 70AH - L3 VRLA 760A - 312188 | $765.52 | Available, ships in 3-6 days |
| 2 | 336708 | Ferrari Complete Battery ECU - 336708 | $206.81 | Special order, ships in 7-14 days |
| 3 | 817638 | Ferrari Battery Sensor F164 Odyssey - 817638 | $372.04 | Special order, ships in 7-14 days |
| 3 | 339034 | Ferrari Battery Sensor Gen2 - 339034 | Superseded | Order 817638 instead |
| 4 | 815156 | Ferrari Battery Breather Pipe - 815156 | $41.76 | Special order, ships in 7-14 days |
| 5 | 199631 | Ferrari Union - 199631 | $0.82 | Available, ships in 3-6 days |
| 6 | 181878 | Ferrari Terminal Clamp - 181878 | $17.92 | Special order, ships in 7-14 days |
