Ferrari SF90 Spider — [ENGINE] - B.15 - INJECTION CONTROL (diagram 0020)
Exploded view of the [engine] - b.15 - injection control on the Ferrari SF90 Spider, with 4 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Spider [ENGINE] - B.15 - INJECTION CONTROL exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-spider/0020.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 853275 | Ferrari Distanziale X Corpo Farfalla - 853275 | $369.30 | Special order, ships in 7-14 days |
| 2 | 977702 | Ferrari Screw - 977702 | $2.18 | Special order, ships in 7-14 days |
| 3 | 910721 | Ferrari Corpo Farfallato Motorizz - 910721 | $787.90 | Special order, ships in 7-14 days |
| 4 | 231624 | Ferrari Allen Screw M6 x 45 - 231624 | Superseded | Order 14305924 instead |
