Ferrari SF90 Spider — [ENGINE] - B.17 - INJECTOR PIPES (diagram 0022)
Exploded view of the [engine] - b.17 - injector pipes on the Ferrari SF90 Spider, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Spider [ENGINE] - B.17 - INJECTOR PIPES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-spider/0022.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 800585 | Ferrari RH Fuel Pipe Compl. With Inj - 800585 | $1,822.04 | Special order, ships in 7-14 days |
| 1 | 838276 | Ferrari Tubo Benzina Dx Cpl Di Iniet - 838276 | Superseded | Order 850856 instead |
| 1 | 850856 | Ferrari Tubo Benzina Dx Cpl Di Iniet - 850856 | $3,707.44 | Special order, ships in 7-14 days |
| 2 | 800587 | Ferrari LH Fuel Pipe Compl. With Inj - 800587 | $1,822.04 | Special order, ships in 7-14 days |
| 2 | 838277 | Ferrari Tubo Benzina Sx Cpl Di Iniet - 838277 | Superseded | Order 850857 instead |
| 2 | 850857 | Ferrari Tubo Benzina Sx Cpl Di Iniet - 850857 | $3,707.44 | Special order, ships in 7-14 days |
| 3 | 800583 | Ferrari Electro-Injector - 800583 | $2,188.65 | Special order, ships in 7-14 days |
| 3 | 827711 | Ferrari Electro-Injector - 827711 | $262.24 | Special order, ships in 7-14 days |
| 4 | 964896 | Ferrari Bracket - Pressure Sensor Cable - 964896 | $51.67 | Special order, ships in 7-14 days |
| 4 | 838883 | Ferrari Sensor Cable Support Bracket - 838883 | $27.06 | Special order, ships in 7-14 days |
| 5 | 70005234 | Ferrari Ferrari Seal Kit - Injectors - 70005234 | $188.20 | Special order, ships in 7-14 days |
| 5 | 70007597 | Ferrari Ferrari Seal Kit - Injectors - 70007597 | $132.75 | Special order, ships in 7-14 days |
