Ferrari SF90 Spider — [VEHICLE TRIM] - E.02 - LATERAL OUTER BODYSHELL (diagram 0098)
Exploded view of the [vehicle trim] - e.02 - lateral outer bodyshell on the Ferrari SF90 Spider, with 35 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Spider [VEHICLE TRIM] - E.02 - LATERAL OUTER BODYSHELL exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-spider/0098.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 15896214 | Ferrari Nut M6 x 5 - 15896214 | Superseded | Order 14039614 instead | |
| 867444 | Ferrari Spoiler Fisso Opt Carb. Cpl - 867444 | Superseded | Order 898537 instead | |
| 1 | 985896884 | Ferrari RH Flank - 985896884 | $35,393.58 | Contact us to order |
| 2 | 985896763 | Ferrari LH Flank - 985896763 | $35,393.58 | Contact us to order |
| 3 | 12647724 | Ferrari Washer - 12647724 | $0.31 | Available, ships in 3-6 days |
| 4 | 16286224 | Ferrari Screw M6x25 - 16286224 | $4.77 | Special order, ships in 7-14 days |
| 5 | 985865290 | Ferrari Compl. RH Front Fender - Version with Shields - 985865290 | $9,373.78 | Contact us to order |
| 5 | 985830985 | Ferrari Parafango Ant. Dx Cpl Primer - 985830985 | $9,184.10 | Special order, ships in 7-14 days |
| 6 | 985865292 | Ferrari Parafango Ant Sx Cpl Scudett - 985865292 | $9,373.78 | Special order, ships in 7-14 days |
| 6 | 985830940 | Ferrari Parafango Ant. Sx Cpl Primer - 985830940 | $9,184.10 | Special order, ships in 7-14 days |
| 7 | 88187400 | Ferrari Spessore Di Regolaz.Ant. Sp. - 88187400 | $8.82 | Special order, ships in 7-14 days |
| 7 | 88187600 | Ferrari Spessore Di Regolaz.Ant. Sp. - 88187600 | $8.82 | Special order, ships in 7-14 days |
| 8 | 985897634 | Ferrari Compl. Upper Windscreen Cros - 985897634 | $1,107.99 | Special order, ships in 7-14 days |
| 9 | 14639591 | Ferrari Rivet - 14639591 | $3.03 | Available, ships in 3-6 days |
| 10 | 898531 | Ferrari Spoiler Mobile Opt Carb Cpl - 898531 | $17,636.82 | Contact us to order |
| 10 | 953882 | Ferrari Spoiler Mobile Opt Carb Cpl - 953882 | Superseded | Order 898531 instead |
| 10 | 985830813 | Ferrari Spoiler Mobile Primer - 985830813 | $5,796.86 | Special order, ships in 7-14 days |
| 10 | 70006947 | Ferrari Variable Geom. Spoiler - 70006947 | $41,698.44 | Contact us to order |
| 11 | 70006946 | Ferrari Rear Spoiler - 70006946 | $41,698.44 | Contact us to order |
| 11 | 813813 | Ferrari Rear Spoiler - 813813 | Superseded | Order 898537 instead |
| 11 | 898537 | Ferrari Rear Spoiler - 898537 | $14,335.04 | Contact us to order |
| 11 | 985830960 | Ferrari Spoiler Posteriore Primer - 985830960 | $9,600.46 | Special order, ships in 7-14 days |
| 12 | 87583800 | Ferrari Adjuster Shim 1.0mm - 87583800 | $3.68 | Special order, ships in 7-14 days |
| 12 | 87583700 | Ferrari Fork Adjuster Shim - 87583700 | $3.91 | Special order, ships in 7-14 days |
| 12 | 921747 | Ferrari Spess.Curvo Di Regolaz.A For - 921747 | Superseded | Order 87583800 instead |
| 12 | 921748 | Ferrari Spess.Curvo Di Regolaz.A For - 921748 | $12.29 | Special order, ships in 7-14 days |
| 13 | 10523178 | Ferrari Washer - 10523178 | $1.97 | Special order, ships in 7-14 days |
| 14 | 13046114 | Ferrari Flanged Nut - 13046114 | $0.31 | Available, ships in 3-6 days |
| 14 | 14059290 | Ferrari Flanged Nut M6 - 14059290 | $2.82 | Available, ships in 3-6 days |
| 14 | 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days |
| 14 | 911976 | Ferrari Wide Flange Hex Nut - 911976 | $24.02 | Special order, ships in 7-14 days |
| 15 | 921749 | Ferrari Spess.Con Piego Di Regol.A F - 921749 | $15.74 | Special order, ships in 7-14 days |
| 15 | 921750 | Ferrari Spess.Con Piego Di Regol.A F - 921750 | $14.26 | Special order, ships in 7-14 days |
| 16 | 900885 | Ferrari Adjustment Shim - 900885 | Superseded | Order 87583800 instead |
| 16 | 900889 | Ferrari Adjustment Shim - 900889 | Superseded | Order 87583700 instead |
