Ferrari SF90 Spider — [VEHICLE TRIM] - E.12 - ROLLBAR (diagram 0108)
Exploded view of the [vehicle trim] - e.12 - rollbar on the Ferrari SF90 Spider, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Spider [VEHICLE TRIM] - E.12 - ROLLBAR exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-spider/0108.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12640606 | Ferrari Washer - 12640606 | Superseded | Order 12640678 instead | |
| 12640608 | Ferrari Washer - 12640608 | Superseded | Order 12640678 instead | |
| 12640677 | Ferrari Washer - 12640677 | Superseded | Order 12640678 instead | |
| 12643711 | Ferrari Washer - 12643711 | Superseded | Order 12643724 instead | |
| 12643721 | Ferrari Washer - 12643721 | Superseded | Order 12643724 instead | |
| 14499301 | Ferrari Washer - 14499301 | Superseded | Order 12643724 instead | |
| 1 | 812858 | Ferrari Rinf. Collegamento Montante - 812858 | Superseded | Order 896217 instead |
| 1 | 896217 | Ferrari Rinf. Collegamento Montante - 896217 | $418.56 | Special order, ships in 7-14 days |
| 2 | 812859 | Ferrari Rinf. Collegamento Montante - 812859 | Superseded | Order 896197 instead |
| 2 | 896197 | Ferrari Rinf. Collegamento Montante - 896197 | $418.56 | Special order, ships in 7-14 days |
| 3 | 13578301 | Ferrari Washer - 13578301 | $0.17 | Special order, ships in 7-14 days |
| 4 | 13046214 | Ferrari Nut - 13046214 | $0.73 | Special order, ships in 7-14 days |
| 5 | 12640678 | Ferrari Washer 6.15x25x2 - 12640678 | $3.47 | Available, ships in 3-6 days |
| 6 | 791263 | Ferrari Flanged Screw M6 x 45 - 791263 | $0.82 | Special order, ships in 7-14 days |
| 7 | 967777 | Ferrari Front Roll Bar Reinforcement Bracket - 967777 | $51.67 | Special order, ships in 7-14 days |
| 8 | 852947 | Ferrari Spessore 1Mm - 852947 | $5.44 | Special order, ships in 7-14 days |
| 9 | 12643724 | Ferrari/Maserati Washer - 12643724 | $0.20 | In stock |
| 10 | 16286134 | Ferrari Screw M6x20 - 16286134 | $28.42 | Special order, ships in 7-14 days |
| 11 | 16287234 | Ferrari SCREW - 16287234 | $1.05 | Available, ships in 3-6 days |
| 11 | 903295 | Ferrari Screw - 903295 | $1.42 | Special order, ships in 7-14 days |
