Ferrari SF90 Spider — [VEHICLE TRIM] - E.17 - FRONT WHEELHOUSE (diagram 0116)
Exploded view of the [vehicle trim] - e.17 - front wheelhouse on the Ferrari SF90 Spider, with 8 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Spider [VEHICLE TRIM] - E.17 - FRONT WHEELHOUSE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-spider/0116.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 881061 | Ferrari Screw M6x18 with Washer - 881061 | Superseded | Order 936581 instead | |
| 1 | 852192 | Ferrari Passaruota Anteriore Dx Cpl - 852192 | $503.37 | Special order, ships in 7-14 days |
| 1 | 913372 | Ferrari Passaruota Anteriore Dx Cpl - 913372 | Superseded | Order 852192 instead |
| 2 | 852189 | Ferrari Passaruota Anteriore Sx Cpl - 852189 | $503.37 | Special order, ships in 7-14 days |
| 2 | 913370 | Ferrari Passaruota Anteriore Sx Cpl - 913370 | Superseded | Order 852189 instead |
| 3 | 936581 | Ferrari M6x18 Screw With Captive Washer - 936581 | $1.34 | Special order, ships in 7-14 days |
| 4 | 84247400 | Ferrari Female Clip - 84247400 | $2.59 | Available, ships in 3-6 days |
| 5 | 84247300 | Ferrari Male Clip - 84247300 | $2.82 | Available, ships in 3-6 days |
